T r a n s a i r ®
Optimising the performance of all machinery and tools
connected to the system
The components and connectors of Transair® distribution systems are
designed to be leak-free without obstructing the passage of the air,
thus ensuring excellent flow rates and a reduction in both pressure drops
and operating costs.
Aluminium pipe to ensure high quality air
To ensure that the air distributed remains of constant, lasting quality,
Transair® pipe is made of aluminium to prevent corrosion.
Quick installation by immediate connection between
components
As industrial production systems must now be able to respond quickly to
meet requirements for flexibility and adaptability, one of the main
advantages of Transair® technology is that all components can be
connected quickly. An air distribution system can, therefore, be assembled,
dismantled or modified easily, 7 times faster than a galvanised steel system,
without delaying or disrupting production.
A wide range of products and accessories
Transair® 's wide range of connectors and pipe sizes can meet the most
exacting requirements of many sectors of industry:
- maximum flow rate: 3045 m3/h (1790 cfm)
(Ø 63 pipes, 30 m long – operating pressure: 8 bar – pressure drop: 5%)
- maximum operating pressure: 16 bar (ask us for details of the
temperature range)
- gases: compressed air, vacuum, inert gases (argon, nitrogen – information
for other gases can be provided on request)
