Width
025(1/4") 031(5/16") 037(3/8")
Belt
Length No. Approx. Approx. Approx.
& Pitch of List Weight List Weight List Weight
Code Teeth Price (lbs.) Price (lbs.) Price (lbs.)
54XL 27 $2.84 .005 $3.28 .007 $3.72 .008
60XL 30 2.92 .006 3.40 .008 3.84 .009
70XL 35 3.00 .007 3.48 .009 4.00 .011
80XL 40 3.08 .008 3.60 .010 4.12 .012
88XL 44 3.14 .009 3.70 .011 4.20 .014
90XL 45 3.16 .009 3.72 .011 4.24 .014
94XL 47 3.20 .010 3.74 .012 4.28 .015
98XL 49 3.24 .010 3.74 .013 4.30 .015
100XL 50 3.28 .010 3.80 .013 4.36 .015
102XL 51 3.34 .010 3.88 .013 4.48 .015
106XL 53 3.34 .011 3.88 .013 4.48 .016
110XL 55 3.36 .011 3.92 .014 4.52 .017
120XL 60 3.44 .012 4.04 .015 4.60 .019
128XL 64 3.50 .013 4.14 .016 4.70 .020
130XL 65 3.52 .013 4.16 .016 4.76 .020
134XL 67 * .013 * .017 * .020
136XL 68 * .014 * .018 * .021
140XL 70 3.64 .014 4.24 .018 4.88 .022
142XL 71 3.66 .014 4.26 .018 4.90 .023
150XL 75 3.72 .015 4.36 .019 5.00 .023
156XL 78 3.80 .016 4.48 .020 5.16 .024
160XL 80 3.80 .016 4.48 .020 5.16 .025
162XL 81 3.82 .016 4.50 .021 5.18 .026
170XL 85 3.88 .017 4.56 .022 5.24 .026
180XL 90 3.96 .018 4.68 .023 5.40 .028
182XL 91 4.00 .018 4.70 .023 5.42 .028
188XL 94 4.06 .019 4.78 .024 5.48 .029
190XL 95 4.08 .019 4.80 .024 5.52 .029
194XL 97 4.16 .020 4.88 .025 5.64 .030
200XL 100 4.16 .020 4.88 .025 5.64 .031
210XL 105 4.24 .021 5.00 .026 5.76 .032
214XL 107 4.28 .021 5.08 .027 5.84 .033
220XL 110 4.32 .022 5.12 .028 5.92 .034
228XL 114 4.42 .023 5.20 .029 5.96 .035
230XL 115 4.44 .023 5.24 .029 6.00 .035
234XL 117 4.48 .023 5.28 .030 6.08 .036
240XL 120 4.52 .024 5.32 .031 6.16 .037
250XL 125 4.60 .025 5.44 .032 6.28 .039
254XL 127 4.64 .026 5.48 .033 6.34 .040
260XL 130 4.68 .026 5.52 .033 6.40 .040
270XL 135 4.72 .029 5.70 .034 6.58 .041
274XL 137 4.74 .029 5.75 .035 6.61 .042
276XL 138 4.76 .029 5.80 .035 6.64 .042
280XL 140 4.88 .029 5.84 .036 6.68 .043
290XL 145 4.92 .029 5.88 .038 6.80 .045
310XL 155 5.12 .031 6.08 .039 7.04 .047
316XL 158 5.24 .032 6.12 .040 7.08 .048
320XL 160 5.24 .032 6.20 .041 7.16 .049
322XL 161 5.26 .032 6.26 .041 7.19 .049
330XL 165 5.28 .033 6.32 .042 7.32 .050
340XL 170 5.40 .034 6.39 .042 7.40 .051
344XL 172 5.40 .034 6.46 .043 7.48 .051
348XL 174 5.40 .035 6.39 .044 7.40 .053
350XL 175 5.46 .035 6.50 .044 7.54 .053
352XL 176 5.48 .035 6.52 .044 7.56 .053
364XL 182 5.60 .036 6.64 .046 7.72 .055
380XL 190 5.76 .038 6.88 .048 7.98 .058
390XL 195 5.84 .039 6.96 .049 8.08 .059
392XL 196 5.86 .039 6.98 .049 8.10 .059
412XL 206 6.03 .040 7.19 .051 8.32 .061
414XL 207 6.00 .041 7.13 .051 8.27 .062
434XL 217 6.20 .043 7.40 .054 8.56 .064
450XL 225 6.36 .045 7.67 .058 8.84 .069
460XL 230 6.44 .046 7.84 .059 8.96 .070
490XL 245 6.68 .049 8.04 .061 9.36 .073
1280XL 640 13.26 1.27 15.96 1.59 18.57 1.91
* Price on Application
Extra Light 1/5-inch
(XL) Pitch Timing Belts Standard Timing Belts
Oil, heat and abrasion-resistant.
Stock timing belts are listed below. They
have fiberglass tension members, neoprene
body with nylon covered teeth, all bonded
together for maximum strength.
For non-stock widths, Jason cuts specified widths
from our large supply of timing belt sleeves on
special order.
Mini-pitch MXL (.080-inch pitch) timing belts are
also available.
Jason timing belts are specified by belt length in
inches times 10, belt pitch code and a three-digit belt
width code which is the decimal inch-width multiplied
by 100. A sample specification is shown below.
240 – L – 075
Length Pitch Width
(24.0-inches) (3/8-inch) (.75 inches)
Width
050(1/2") 075(3/4") 100(1")
Belt
Length No. Approx. Approx. Approx.
& Pitch of List Weight List Weight List Weight
Code Teeth Price (lbs.) Price (lbs.) Price (lbs.)
124L 33 $7.68 .02 $10.92 .05 $14.00 .07
135L 36 8.36 .06 11.89 .05 15.24 .07
150L 40 8.48 .03 12.12 .05 15.60 .07
165L 44 8.72 .03 12.52 .06 16.14 .08
169L 44 8.86 .03 12.72 .06 16.47 .08
173L 46 9.00 .03 12.92 .06 16.70 .08
187L 50 9.24 .04 13.32 .07 17.24 .09
202L 54 9.80 .04 14.12 .08 18.34 .09
210L 56 10.04 .04 14.52 .08 18.84 .09
225L 60 10.32 .05 14.92 .08 19.38 .10
236L 63 10.46 .06 15.19 .08 19.92 .12
240L 64 10.84 .06 15.72 .08 20.48 .12
244L 65 10.95 .06 15.53 .08 20.70 .12
255L 68 11.08 .06 16.12 .09 21.02 .12
270L 72 11.60 .06 16.92 .10 22.08 .13
285L 76 11.88 .07 17.36 .10 22.62 .14
300L 80 12.40 .07 18.12 .11 23.72 .14
315L 84 12.64 .07 18.56 .12 24.26 .15
320L 85 12.90 .07 18.90 .12 24.70 .15
322L 86 12.92 .07 18.96 .12 24.80 .15
345L 92 13.44 .08 19.76 .13 25.86 .16
367L 98 13.92 .08 20.56 .13 26.94 .17
375L 100 14.20 .08 21.30 .13 28.20 .17
390L 104 14.72 .09 21.76 .14 28.54 .18
405L 108 14.96 .09 22.20 .14 29.10 .19
420L 112 15.48 .10 22.96 .15 30.18 .20
424L 113 15.58 .10 23.12 .16 30.38 .21
424L 113 15.58 .10 23.12 .16 30.38 .21
427L 114 15.58 .10 22.96 .16 30.88 .21
450L 120 16.28 .11 24.20 .16 31.78 .21
480L 128 17.08 .12 25.40 .17 33.42 .23
510L 136 17.60 .12 26.20 .18 34.52 .24
525L 140 * .12 * .19 * .25
540L 144 18.64 .13 27.80 .20 36.66 .26
548L 146 18.64 .13 27.90 .20 37.20 .26
581L 155 19.68 .13 28.99 .20 38.30 .27
600L 160 20.20 .13 30.24 .21 39.90 .28
660L 176 21.76 .14 33.26 .23 43.89 .29
728L 194 23.32 .15 35.08 .25 45.28 .30
731L 195 23.42 .15 35.08 .25 46.38 .30
817L 218 26.80 .18 40.20 .29 53.60 .36
* Price on Application
Light 3/8-inch (L) Pitch Timing Belts
8
Standard Timing Belts
