6
Dual HTB
®
Timing Belts and Tiger Synchronous Belts
Jason developed the
Tiger Belt
®
to extend the synchronous
belt application range.
Special aramid reinforced compounds, along with improved tooth
facing and tensile members provide the muscle for the increased
horsepower ratings; up to three times that of standard HTB
®
belts.
Laboratory and customer tested tough!
Tiger Belts
®
may also be ordered in the standard 8mm pitch HTB
®
widths of 20mm, 30mm, 50mm and 85mm, as well as in standard
14mm pitch HTB
®
widths of 40mm, 55mm, 85mm, 115mm and
170mm.
HTB
®
drives utilizing
TigerBelts
®
as direct replacements for original
HTB
®
belts will see greatly improved belt life.
Tiger Belts
®
should be installed so that the deflection at midspan is
1/64” for every inch of span when the force specified in the table
below is applied.
Tiger
®
Synchronous Belts
Jason’s Maximum Performance
High-Torque Belt
Dual 8mm
HTB Timing Belts
Width(mm)
Belt
20
30
50
85
Profile,
Length
No.
Approx.
Approx.
Approx.
Approx.
& Pitch
of
List
Weight
List
Weight
List
Weight
List
Weight
Code
Teeth
Price
(lbs.)
Price
(lbs.)
Price
(lbs.)
Price
(lbs.)
D480-8M
60
$29.40
.14
$45.00
.22
$71.75
.36
$119.25
.61
D536-8M
67
30.40
.15
47.00
.25
75.25
.41
125.50
.67
D560-8M
70
31.75
.17
49.25
.26
78.75
.42
131.00
.70
D600-8M
75
33.35
.18
52.00
.27
83.25
.45
138.75
.76
D632-8M
79
33.80
.19
52.50
.29
84.50
.47
141.00
.80
D640-8M
80
34.30
.20
53.25
.30
85.50
.48
142.75
.82
D720-8M
90
36.80
.21
57.25
.32
92.50
.54
154.50
.91
D800-8M
100
40.25
.23
63.00
.35
101.75
.60
170.25
1.03
D840-8M
105
41.50
.25
65.00
.37
105.25
.62
176.15
1.06
D880-8M
110
42.80
.27
67.00
.39
108.75
.65
182.00
1.12
D920-8M
115
44.05
.28
69.00
.40
111.25
.68
187.90
1.17
D960-8M
120
45.31
.29
71.00
.43
115.75
.71
193.75
1.22
D1040-8M
130
47.85
.31
75.25
.46
122.50
.79
205.50
1.32
D1120-8M
140
50.35
.33
79.25
.50
129.50
.83
217.25
1.00
D1152-8M
144
53.15
.34
83.50
.52
136.50
.87
229.00
1.47
Width(mm)
Belt
20
30
50
85
Profile,
Length
No.
Approx.
Approx.
Approx.
Approx.
& Pitch
of
List
Weight
List
Weight
List
Weight
List
Weight
Code Teeth
Price
(lbs.)
Price
(lbs.)
Price
(lbs.)
Price
(lbs.)
D1200-8M
150
$53.15
.35
$83.50
.53
$136.50
.90
$229.00
1.50
D1224-8M
153
55.65
.37
87.50
.55
143.50
.93
240.75
1.58
D1280-8M
160
55.65
.39
87.50
.58
143.50
.95
240.75
1.61
D1440-8M
180
57.05
.43
95.75
.64
157.25
1.08
264.25
1.82
D1600-8M
200
66.00
.48
104.00
.71
171.25
1.19
288.00
2.03
D1760-8M
220
71.10
.52
112.25
.77
185.00
1.31
311.25
2.20
D1800-8M
225
72.70
.54
114.75
.80
189.75
1.34
319.25
2.29
D2000-8M
250
79.60
.60
125.75
.88
208.25
1.49
350.50
2.52
D2104-8M
263
88.19
.63
132.28
.95
220.47
1.57
374.79
2.67
D2400-8M
300
93.15
.72
147.75
1.07
245.25
1.76
414.75
3.02
D2600-8M
325
100.75
.79
159.00
1.15
266.75
1.92
446.00
3.27
D2800-8M
350
107.20
.85
169.50
1.22
282.25
2.06
476.00
3.52
D3048-8M
381
112.78
.93
174.57
1.38
307.25
2.31
522.33
3.93
D3600-8M
450
133.20
1.10
206.18
1.65
343.63
2.76
604.02
4.69
D4400-8M
550
162.80
1.35
252.00
1.39
429.00
3.22
738.25
5.52
®
