It is soft and flexible with an exceptionally
uniform density; Under the surface is a
microscopic structure that makes this remarkable
material one of the strongest. most versatile gas-
ket materials available today!
LASTS LONGER, SAVES TIME, COST AND
IS VERY VERSATILE
Manufactured in our ISO 9002 facility; INERTEX
UHF Gasket Tape is made of 100% expanded virgin
PTFE. INERTEX alone uses a patented process
that produces a .uniform and Highly fibrillated
microstructure with thousands of small fibers running
in many directions. These create a soft and pliable,
yet, very tough gasket material that can seal surface
irregularities up to .DO?"in depth with a relatively low
clamping force. INERTEX UHF Gasket Tape is
FDA suitable and comes with a full paper covered
self-adhesive backing that makes installation simple.
.Excellent for use on glass lined, plastic, and FRP plastic flanges
.Can be used on odd shaped flanges
.Can be used as an insulating tape
.Excellent for repairing worn spiral wound and metal gaskets
.Eliminates the need for etched PTFE
.Wider widths are useful for volume cutting of gaskets
.Easy to use, will not unravel and is simple to install
MANY APPLICATIONS
INERTEX UHF Gasket Tape can be used wherever a thin
gasket is needed and wherever an FDA suitable material is
required. Industries currently using INERTEX UHF Gasket
Tape Include:
INERTEX UHF Gasket Tape
FOR DEPENDABLE PERFORMANCE
.Petrochemical
Production
.Pharmaceutical
.Power Generation
.Pulp and Paper
.Pump and Valve
.Chemical Manufacturing
and Transporting
.Distilling
.Food Equipment Manufacturing
.Food Processing
.Heating and Air
.Automotive Paint Booths
.100% expanded virgin PTFE
.Withstands a wide range of temperatures from
-450°F to +600°F
.Pressures from full vacuum to 3000 PSI
.Unaffected by common chemicals, pH range: 0 -14
.Soft and compressible under low bolt loads
.No creep or cold flow
.Non-contaminating, non-toxic, silicone free
.FDA suitable (FDA 21 CFR177.1550)
.Helps you meet tough EPA standards for fugitive
flange emissions
THE FAMILY
The INERTEX family representsa full line of 100% expanded
PTFE gasketing and packing. Other products from the
INERT EX family are as follows:
STANDARD AND CUSTOM
SIZES FOR ANY NEED .INERTEX UHF Joint Sealant
.INERTEX SQ-S Gasket Sheet
.INERTEX EZ-Seal Insertable Gaskets
.INERTEX Valve Stem Packing INERTEX UHF Gasket Tape standard sizes are
listed below. Lengths are available in either 50 or 100
feet with the exception of 8" wide (5 to 25 feet). All
sizes include a full paper covered self-adhesive back-
ing. Custom sizes are available for special applications.
Custom designed products are also available upon request.
Please call our technical department at 1-800-732-5835 for
your special requirements.
1-800-732-5835 FAX: 1-800-732-8828
Distributed By:
MFG. UNDER U.S. PATENTNO. 5,098,625 GT BROR 35-5
