first 100%expandedPTFE in a true 60" x 60" for-

mat. This material is manufacturedby our propri-

etary isotropic-expansion processwhichbreaksall

the rules traditional to gasketmaterial manufactur-

ing of the past. 9Sotropic-expansion providesa highly fibrillat-

edmicrostructurewith nearlyequal tensile strengthin everydirec-

tion. This unique structuremaximizes performancepredictability

and stability while minimizing creep and cold flow. INERTEX

SQ-S definitly is an all-purpose gasket sheet that is setting the

new standardin gaskettechnology.

INERTEX SQ-Shas an unlimited shelf life and will not become

brittle, age,or otherwisedeterioratein the application. This mate-

rial is unaffected by UV, ozone,and corona. It is easily hand or

die cut. And, when necessary,INERTEXSQ-S can be removed

easily from flange surfaces due to the non-sticking nature of

PTFE.

QUALITYASSURANCE

INERTEXSQ-Sis manufacturedin our ISO 9002certified facili-

ty (Certification #94/4207). To assure receiving INERTEXSQ-S

in the best condition eachand every time, all sheetsare individu-

ally rolled onto a papertube and shrink-wrappedbeforebeing put

into a blister sleeveand sturdybox.

ONE COLOR

ONE CHOICE

INERTEX SQ-S is made of 100%virgin PTFE. Our isotropic-

expansion process completely eliminates the need for binders,

fillers, or pigments. This material is engineeredto replace all

filled PTFE gasketsheetmaterials in various colors suchas fawn,

blue, off-white, green,or orange. It will eliminate the possibility

of misuseof these different colored gasketmaterials. Plus, gas-

keting inventories will be greatly reduced with INERTEX SQ-S,

the one,all-encompassinggasketmaterial.

PURE ...INTEGRAL

INERTEXSQ-S is so pure that it far exceedsthe requirementsset

forth in the rigid SEMASPEC92010934B-STDaccordingto test-

ing performed by a SEMATECH recognized laboratory. And,

since it doesnot particulate, INERTEXSQ-Sis the choice for han-

dling ultra-pure fluids suchasultra-pure water,bio-tech,andphar-

maceuticals.

SOFJ:

BUTSTRONG

INERTEXSQ-S is very soft and extremelycompressiblewith rel-

atively light torque. It can be applied in FRP,porcelain, plastic,

and glass-linedpiping or vessels. Yet, this material is very strong

andtough. It canwithstand compressiveloadsof over40,000 psi

without affecting its sealingcapability. INERTEXSQ-Sis virtual-

ly impossible to abuse.

THETIGHTEST

According to the testing done by Ecole PolytechniqueTightness

Testing ResearchLaboratory (TTRL), INERTEXSQ-S is one of

the tightest sealing gasketmaterials in theworld. It can helpmeet

the most strict regulations of the Clean Air Act. Coupled with

excellent chemical compatibility with all VOC's, RAP's, and

RON's, INERTEX SQ-S becomesthe ultimate resolution to the

EPAissue.

THEFAMILY

INERTEX family representsa full line of 100%expandedPTFE

gasket~g andpacking. Otherproducts of INERTEX are as fol-

lows:

.INERTEX UHF Joint Sealant

.INERTEX UHF GasketTape

.INERTEX EZ-Seal lnsertableGaskets

.INERTEX Valve StemPacking

Customdesignedproductsarealsoavailable uponrequest. Please

call our technical departmentat 1-800-732-5835for your special

requirements.
