ChlorSafeTM Product Specifications
ChlorSafeTM Fittings
Inside
Diameter
(in.)
Number of
Braids
(#)
Outside
Diameter
(in.)
Minimum
Dynamic Bend
Radius (in.)
Maximum
Working
Pressure* (psi)
Minimum
Burst Pressure
(psi)
1/2 1
2
.83
.89 8 500 2500
3/4
1
2
1.22
1.28 9 375 1875
1
1
2
1.53
1.59 10 375 1875
1 1/2
1
2
2.16
2.24 11 375 1875
2
1
2
2.69
2.77 13 375 1875
ChlorSafeTM Part Numbers AF 6720 - (Single Braid) • AF 6722 - (Double Braid)
ChlorSafeTM Product Documentation
Hose Master Inc. maintains production documentation for seven years, including:
• Welder Training
• Fabrication
• Testing
• Inspection
• Positive Material Identification
• Burst Test Conformance
ChlorSafeTM Product Identification
All ChlorSafeTM assemblies are etched with:
• Unique Serial Number
• Company Name
• Date of Fabrication
• Minimum Bend Radius
• Compliance with Chlorine Institute Pamphlet 6, Appendix A
Per Chlorine Institute specifications, pressure ratings represent a 5:1 safety factor
* For pressures in excess of Chlorine Institute Standards, please consult the factory
ChlorSafeTM assemblies are available in three different configurations:
• 276 alloy Schedule 80 Male NPT x 276 alloy Schedule 80 Male NPT
• 276 alloy Schedule 80 Male NPT x 276 alloy “A” Stub with a 300# Carbon Steel Lap
Joint Flange (Floating)
• 276 alloy “A” Stub with a Carbon Steel 300# Lap Joint Flange (Floating) x 276 alloy
“A” Stub with a Carbon Steel 300# Lap Joint Flange (Floating)
ChlorSafe; Rev NR; 7/2008
