Bronzeflex
Bronzeflex is Hose Master’s heavy-duty corrugated hose, designed for use in those applications
that specifcally require a bronze hose.
Explanation of Bronzefex Part Numbers
BF 11 _______
Braid Code
Example: AF1110 = Bronze corrugated metal hose with a single bronze braid
• The minimum bend radius is measured from the centerline of the hose
• The working pressure decreases with temperature - obtain derating factor on page 33 in Technical Information
• For rapid pressure fuctuations, consult factory
Braid Codes
00 - Unbraided
10 - Single Bronze Braid
11 - Double Bronze Braid
Inside
Diameter
(in.)
Number of
Braids
(#)
Outside
Diameter
(in.)
Static
Minimum
Bend
Radius
(in.)
Dynamic
Minimum
Bend
Radius
(in.)
Maximum
Working
Pressure
(psi)
Burst
Pressure
(psi)
Weight
Per Foot
(lbs.)
3/8
0
1
2
0.61
0.67
0.73
2.0 6.0
60
704
936
n/a
2815
3744
0.16
0.29
0.42
1/2
0
1
2
0.76
0.81
0.87
2.3 7.0
50
566
753
n/a
2265
3012
0.23
0.38
0.53
3/4
0
1
2
1.05
1.10
1.16
2.5 8.0
30
468
622
n/a
1870
2487
0.33
0.55
0.77
1
0
1
2
1.34
1.42
1.50
3.0 9.0
26
334
444
n/a
1335
1776
0.41
0.68
0.95
1 1/4
0
1
2
1.66
1.74
1.82
3.5 10.0
16
306
407
n/a
1225
1629
0.71
1.15
1.59
1 1/2
0
1
2
1.89
1.96
2.03
4.0 10.0
15
297
395
n/a
1187
1579
0.93
1.47
2.01
2
0
1
2
2.48
2.57
2.66
6.0 11.0
10
210
279
n/a
840
1117
1.00
1.62
2.24
2 1/2
0
1
2
3.33
3.45
3.57
8.5 16.0
8
194
258
n/a
775
1031
1.70
2.68
3.66
3
0
1
2
3.89
4.01
4.13
10.0 20.0
5
166
221
n/a
665
884
2.10
3.30
4.50
16
