CTS Copper System
www.anvilintl.com 118
CTS Copper Fittings are produced with groove and cup
ends in a variety of ftting confgurations. The fttings are
constructed to ASTM B75 UNS C12200 with minimum
copper content of 99.9%. Fitting pressure ratings match
the ratings of the Figure 6400 Coupling.
Dimensions/Weights — Elbows, Tees & Caps
Nominal
Size
Copper Tube
Diameter
Fig. 6050
90° Elbow
Fig. 6051
45° Elbow
Fig. 6060
Tee
Fig. 6074
Cap
C to E Wt. Ea. C to E Wt. Ea. C to E Wt. Ea. E to E Wt. Ea.
In. In./mm In./mm Lbs./kg In./mm Lbs./kg In./mm Lbs./kg In./mm Lbs./kg
2 2.125
54.0
2.91
74
0.75
0.34
2.19
56
0.61
0.28
2.69
68
1.45
0.66
2.00
51
0.36
0.16
21 /2 2.625
66.7
3.31
84
1.15
0.52
2.31
59
0.89
0.40
3.20
81
2.37
1.07
2.00
51
0.50
0.23
3 3.125
79.4
3.81
97
1.88
0.85
2.59
66
1.38
0.63
3.52
89
3.38
1.53
2.00
51
0.69
0.31
4 4.125
104.8
4.75
121
4.07
1.85
3.19
81
2.99
1.36
4.25
108
5.77
2.62
2.00
51
1.15
0.52
5 5.125
130.2
5.94
151
6.94
3.15
3.25
83
4.00
1.81
5.94
151
12.84
5.82
2.75
70
1.81
0.82
6 6.125
155.6
6.94
176
11.12
5.04
3.63
92
6.16
2.79
6.94
176
21.00
9.52
3.13
80
2.68
1.22
8 8.125
206.4
7.75
197
21.81
9.89
4.25
108
13.66
6.20
7.75
197
21.81
9.89
–
–
–
–
Fig. 6050 Fig. 6051 Fig. 6060 Fig. 6074
CTS Copper Fittings
C to E
C to E
E to E
C to E
