Page 4 - Cover Front

®
*Prices Subject To Change Without Notice • EMAIL: sales@grnleafinc.com • WEBSITE: http://www.grnleafinc.com
T
E
E
L
H
A
N
D
L
E
D
B
A
L
L
V
A
L
V
E
S
2
VXM 204 FP
VXA 204 FP
VXMA 204 FP VXMM 204 FP
X SERIES features
• Stainless Steel Bolts
• Stainless Steel Handles with New Ergonomic Design and Locking feature for added safety. (VX 204 Series also available with T Handle)
• Precision molded in polypropylene. Polypropylene is reinforced with fiberglass for additional strength.
• Self-aligning ball moves freely against the Teflon® seats for smooth operation.
The valve opens and closes with little pressure on the handle.
• Ball is diamond turned, after molding, to make it spherically perfect, which provides precise contact between ball and seats.
• Viton® “O” rings.
• Teflon® self-lubricating stem bushings and seats cannot stick or bind.
• 4 Bolt — Maximum operating pressure 150 PSI@ 70ºF. 75 PSI@ 150ºF.
• 6 Bolt — Maximum operating pressure 100 PSI@ 70ºF. 75 PSI@ 150ºF.
VX 204 FP
Xtra Small Valves “XS Valves”
VX 204 FP
VXM 204 FP
VXA 204 FP
VXMA 204 FP
VXMM 204 FP
PART # DESCRIPTION
2” Female NPT x 2” Female NPT, Full Port
2” Female NPT x 2” Male NPT, Full Port
2” Female NPT x 2” Male Adapter, Full Port
2” Male NPT x 2” Male Adapter, Full Port
2” Male NPT x 2” Male NPT, Full Port
** Plastic T-handles
available by request
for 204 XS Series only.
