Belt characteristics
• Polyurethane timing belt with round tooth profile and high ten-
sile load tension cords. Produced according to ISO 13050
• Metric pitch 8 mm
• The round tooth profile allows a uniform load distribution that
guarantees high performances, high transmissible torque and
precise tooth engagement.
• Widely used in linear positioning, medium power transmission
applications.
• Width tolerance: ±0,5 [mm]
• Length tolerance: ±0,5 [mm/m]
• Thickness tolerance: ±0,2 [mm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
Belt width
b
[mm]
Allowable
tensile load
Type M
F
Tzul
[N]
Allowable
tensile load
Type V
F
Tzul
[N]
Breaking
load
Type M
F
Br
[N]
Specific
spring rate
Cspez
[N]
Weight
[kg/m]
10
15
20
30
50
85
100
1340
2020
2910
4260
7170
12770
14560
336000
504000
728000
1064000
1792000
3192000
3640000
5700
8550
12350
18050
30400
54150
61750
670
1010
1455
2130
3585
6385
7280
0,07
0,10
0,14
0,21
0,35
0,59
0,69
Tooth shear strength
Other widths are available on request.
0
74,00
20
72,62
40
71,34
60
70,16
80
69,07
100
68,07
200
64,09
300
61,68
400
59,03
500
56,71
600
54,66
700
52,84
HTD8M
Technical data
4500 26,63
5000 25,00
5500 23,51
6000 22,15
1900 39,52
2000 38,78
2200 37,39
2400 36,12
2600 34,94
2800 33,83
3000 32,80
3200 31,83
3400 30,91
3600 30,05
3800 29,22
4000 28,44
800
51,20
900
49,71
1000 48,35
1100 47,09
1200 45,93
1300 44,84
1400 43,82
1440 43,43
1500 42,86
1600 41,96
1700 41,10
1800 40,29
Load / Elongation [ % ]
Tooth shear strenght / rpm
The specific load F
Uspez
is the maximum load which one single
belt tooth 1 cm wide can withstand in all operating conditions.
This force is related to the drive rpm.
The total load F
U
transmissible by the belt in the dr ive is
calculated by:
F
U
[N] = F
Uspez
•
z
e
•
b
F
U
[N]
= peripheral force
F
Uspez
[N/cm] = specific load
z
e
= number of teeth in mesh in the small pulley
z
emax
= max. no of teeth in mesh to be considered
for the calculation of the drive
z
emax
= 12 for ELATECH
®
M
z
emax
= 6 for ELATECH
®
V
b [cm]
= belt width in cm
F
Uspez [N/cm]
