24
Belt characteristics
• High performance polyurethane timing belt with HPL steel ten-
sion cords.
• Metric pitch 20 mm
• Specially designed for linear drives
• Tension cords with increased allowable tensile load compared
to standard for lower elongation.
• Produced with special pretension and pitch tolerance to gua-
rantee high positioning precision in linear drives.
• Width tolerance: ±1,0 [mm]
• Thickness tolerance: ±0,4 [mm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
Belt width
b
[mm]
Allowable
tensile load
Type M
F
Tzul
[N]]
Breaking
load
Type M
F
Br
[N]
Specific
spring rate
C
spez
[N]
Weight
[kg/m]
25
32
50
75
100
150
7600
10100
16000
24400
31900
48700
0,28
0,36
0,56
0,84
1,12
1,68
1890000
2520000
3990000
6090000
7980000
12180000
29700
39600
62700
95700
125400
191400
Tooth shear strength
Other widths are available on request.
0
151,40
20
148,56
40
145,89
60
143,38
80
141,01
100
138,78
200
129,43
300
122,28
400
115,96
500
110,45
600
105,61
700
101,31
ATL20
Technical data
4500 39,72
5000 35,90
5500 32,42
6000 29,23
6500 26,29
7000
7500
8000
8500
9000
9500
10000
1900 69,96
2000 68,22
2200 64,97
2400 61,98
2600 59,20
2800 56,62
3000 54,20
3200 51,92
3400 49,77
3600 47,74
3800 45,80
4000 43,96
800
97,44
900
93,93
1000 90,73
1100 87,77
1200 85,02
1300 82,47
1400 80,07
1440 79,16
1500 77,82
1600 75,70
1700 73,69
1800 71,77
Load / Elongation [ % ]
Tooth shear strenght / rpm
The specific load F
Uspez
is the maximum load which one single
belt tooth 1 cm wide can withstand in all operating conditions.
This force is related to the drive rpm.
The total load F
U
transmissible by the belt in the dr ive is
calculated by:
F
U
[N] = F
Uspez
•
z
e
•
b
F
U
[N]
= peripheral force
F
Uspez
[N/cm] = specific load
z
e
= number of teeth in mesh in the small pulley
z
emax
= max. no of teeth in mesh to be considered
for the calculation of the drive
z
emax
= 12 for ELATECH
®
M
z
emax
= 6 for ELATECH
®
V
b [cm]
= belt width in cm
F
Uspez [N/cm]
3.4
