14
Belt characteristics
• Polyurethane timing belt with steel tension cords.
• Metric pitch 5 mm
• Tooth profile and dimension are optimised to guarantee uni-
form load distribution and minimum deformation under load.
• High resistance and low stretch steel cords to guarantee high
stability and low elongation
• Reduced polygonal effect with reduced drive vibration.
• Particularly suitable for linear drives and light power transmis-
sion applications with high axial and angular positioning accu-
racy.
• Width tolerance: ±0,5 [mm]
• Length tolerance: ±0,5 [mm/m]
• Thickness tolerance: ±0,2 [mm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
rpm
F
Uspez
[N/cm]
Belt width
b
[mm]
Allowable
tensile load
Type M
F
Tzul
[N]
Allowable
tensile load
Type V
F
Tzul
[N]
Breaking
load
Type M
F
Br
[N]
Specific
spring rate
C
spez
[N]
Weight
[kg/m]
10
16
25
32
50
75
100
560
1120
1750
2240
3500
5250
7000
140000
280000
437500
560000
875000
1312500
1750000
2000
4000
6250
8000
12500
18750
25000
280
560
875
1120
1750
2625
3500
0,03
0,05
0,09
0,11
0,17
0,26
0,34
Tooth shear strength
Other widths are available on request.
0
36,40
20
35,88
40
35,40
60
34,97
80
34,59
100
34,24
200
32,92
300
31,92
400
30,89
500
29,95
600
29,12
700
28,37
AT5
Technical data
4500 17,18
5000 16,47
5500 15,83
6000 15,24
6500 14,69
7000 14,18
7500 13,71
8000 13,26
8500 12,85
9000 12,45
9500 12,07
10000 11,72
1900 22,73
2000 22,42
2200 21,82
2400 21,28
2600 20,77
2800 20,29
3000 19,85
3200 19,43
3400 19,03
3600 18,66
3800 18,30
4000 17,96
800
27,69
900
27,06
1000 26,49
1100 25,96
1200 25,47
1300 25,01
1400 24,57
1440 24,41
1500 24,16
1600 23,78
1700 23,41
1800 23,07
Load / Elongation [ % ]
Tooth shear strenght / rpm
The specific load F
Uspez
is the maximum load which one single
belt tooth 1 cm wide can withstand in all operating conditions.
This force is related to the drive rpm.
The total load F
U
transmissible by the belt in the dr ive is
calculated by:
F
U
[N] = F
Uspez
•
z
e
•
b
F
U
[N]
= peripheral force
F
Uspez
[N/cm] = specific load
z
e
= number of teeth in mesh in the small pulley
z
emax
= max. no of teeth in mesh to be considered
for the calculation of the drive
z
emax
= 12 for ELATECH
®
M
z
emax
= 6 for ELATECH
®
V
b [cm]
= belt width in cm
F
Uspez [N/cm]
