Compressor O-Ring Tube, Female, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-COTF45-0810 50133-0810 13/32 10.30 1-14 1.10 28 2.01 51
AC-COTF45-1010 50133-1010 1/2 12.70 1-14 1.26 32 1.38 35
AC-COTF45-1210 50133-1210 5/8 15.90 1-14 0.67 17 1.26 32
Compressor O-Ring Tube, Female, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-COTF90-0810 50135-0810 13/32 10.30 1-14 1.93 49 1.77 45
AC-COTF90-1010 50135-1010 1/2 12.70 1-14 2.20 56 1.77 45
AC-COTF90-1210 50135-1210 5/8 15.90 1-14 2.72 69 2.36 60
Compressor O-Ring Tube, Female, 90 Block Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-COTF90B-0810 50137-0810 13/32 10.30 1-14 0.83 21 0.94 24
AC-COTF90B-1010 50137-1010 1/2 12.70 1-14 0.83 21 0.94 24
AC-COTF90B-1210 50137-1210 5/8 15.90 1-14 0.83 21 1.06 27
Compressor O-Ring Tube, Female, R134a Valve, 90 Block Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-COTF134V90B-0810 50145-0810 13/32 10.30 1-14 0.83 21 0.94 24 0.63 16
AC-COTF134V90B-1010 50145-1010 1/2 12.70 1-14 0.83 21 0.94 24 0.51 13
AC-COTF134V90B-1210 50145-1210 5/8 15.90 1-14 0.83 21 1.06 27 0.51 13
Picture Not Available
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
