Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 4 –
GALAXY 4826 Hose
SAE J2064 / Type C / Class II / Low Pressure
For use with Goodyear "AC" Crimp Fittings
Continuous Brand Layline Example
GALAXY by GOODYEAR SAE J2064 Type C Classll 1/2 in (13mm) 4826 - Size 10 Made in USA
GALAXY 4867 Hose
SAE J2064 / Type C / Class l / Low Pressure
For use with Goodyear "AC" Crimp Fittings
Continuous Brand Layline Example
GOODYEAR GALAXY A/C Hose 3/4 IN (19mm) 4867
GALAXY 4890 Hose
SAE J2064 / Type C / Class I / Low Pressure
For use with Goodyear COOL CLIP
™
Fittings
Continuous Brand Layline Example
GALAXY SLE 4890 A/C Hose 13/32 in (10mm) GOODYEAR R134a
Part
Hose Size I.D.
Hose O.D.
Max. Working Pressure Min. Bend Radius Min. Burst Pressure Weight
Number
INCH MM INCH MM PSI
MPA INCH MM PSI
MPA (lbs/foot)
G4890-06 5/16
7.9
.56
14.7
500
3.4
1.0
25
2000
13.8
0.09
G4890-08 13/32
10.3
.69
17.3
500
3.4
1.5
38
2000
13.8
0.12
G4890-10 1/2
12.7
.75
19.4
500
3.4
2.5
63
2000
13.8
0.13
G4890-12 5/8
15.9
.94
23.6
350
2.4
4.0
104
1750
12.1
0.20
Part
Hose Size I.D.
Hose O.D.
Max. Working Pressure Min. Bend Radius Min. Burst Pressure Weight
Number
INCH MM INCH MM PSI
MPA INCH MM PSI
MPA (lbs/foot)
G4867-14 3/4
19.1
1.13
28.6
350
2.4
6.3
160
1750
12.1
0.26
Part
Number
Hose Size I.D.
Hose O.D.
Max. Working Pressure Min. Bend Radius Min. Burst Pressure
Weight
(lbs/foot)
INCH MM INCH MM PSI
MPA INCH MM PSI
MPA
G4826-06 5/16
7.9
0.75
19.1
500
3.4
.6
16
2000
13.8
0.20
G
4826-08 13/32
10.3
0.91
23.0
500
3.4
1.0
25
2000
13.8
0.28
G4826-10
1/2
12.7
1.00
25.4
500
3.4
1.3
32
2000
13.8
0.33
G4826-12
5/8
15.9
1.13
28.6
350
2.4
2.0
50
1750
12.1
0.38
Galaxy
®
Air Conditioning Hose
