Flareless Tube Nuts
Flareless Tube Sleeves
Flareless Tube Sleeves, Metric
Inline Orifice Tubes
O-Ring, for Ford Spring Lock
O-RING ID
Descriptive # Product # INCH MM
GC-OFSL-0006 54450-0006 3/8 9.5
GC-OFSL-0008 54450-0008 1/2 12.7
GC-OFSL-0010 54450-0010 5/8 15.9
GC-OFSL-0012 54450-0012 3/4 19.1
Orifice Tube O.D. Orifice Tube Length
Descriptive # Product # INCH MM INCH MM Description
AC-ILOTORA-0057 50401-0057 .057 1.4 3.50 88.9 Inline Orifice Tube, Ford, Orange
AC-ILOTRED-0062 50401-0062 .062 1.6 3.50 88.9 Inline Orifice Tube, Ford, Red
AC-ILOTBLU-0072 50401-0072 .072 1.8 3.50 88.9 Inline Orifice Tube, Ford, Blue
AC-ILOTBLK-0072 50402-0072 .072 1.8 3.50 88.9 Inline Orifice Tube, GM, Black
AC-ILOTWHI-0072 50403-0072 .072 1.8 3.50 88.9 Inline Orifice Tube, GM, White
Tube O.D.
Descriptive # Product # Thread Size MM
AC-FTSM-0008 50260-0008 8
AC-FTSM-0012 50260-0012 12
AC-FTSM-0015 50260-0015 14.5
Tube O.D.
Descriptive # Product # Thread Size INCH
AC-FTS-0006 50255-0006 3/8
AC-FTS-0008 50255-0008 1/2
AC-FTS-0010 50255-0010 5/8
AC-FTS-0012 50255-0012 3/4
Tube O.D.
Descriptive # Product # Thread Size INCH
AC-FTN-0006 50250-0006 5/8-18 3/8
AC-FTN-0008 50250-0008 3/4-16 1/2
AC-FTN-0010 50250-0010 7/8-14 5/8
AC-FTN-0012 50250-0012 1 1/16-14 3/4
One Source, One System, One Solution. www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 31 –
A/C CLIP FITTING ACCESSORIES
