O-Ring Tube , Male, Swivel, R134a Valve
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTM134V-0606 54730-0606 5/16 7.90 5/8-18
1.06
27
0.63
16
GC-OTM134V-0808 54730-0808 13/32 10.30 3/4-18
1.22
31
0.63
16
GC-OTM134V-1010 54730-1010 1/2 12.70 7/8-18
1.61
41
0.51
13
GC-OTM134V-1210 54730-1210 5/8 15.90 7/8-18
1.73
44
0.51
13
GC-OTM134V-1212 54730-1212 5/8 15.90 1 1/16-16
1.73
44
0.51
13
O-Ring Tube, Male, Swivel, R134a Valve, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE #
PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTM134V90-1010 54735-1010 1/2 12.70 7/8-18 2.05
52
1.65
42
0.51
13
GC-OTM134V90-1210 54735-1210 5/8 15.90 7/8-18 2.05
52
1.65
42
0.51
13
SAE 45 Flare, Female, Swivel
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFFX-0606
54760-0606 5/16 7.90 5/8-18
1.38
35
GC-SFFX-0608
54760-0608 5/16 7.90 3/4-16
1.38
35
GC-SFFX-0806
54760-0806 13/32 10.30 5/8-18
1.77
45
GC-SFFX-0808
54760-0808 13/32 10.30 3/4-16
1.77
45
GC-SFFX-1008
54760-1008 1/2 12.70 3/4-16
1.77
45
GC-SFFX-1010
54760-1010 1/2 12.70 7/8-14
1.97
50
GC-SFFX-1210
54760-1210 5/8 15.90 7/8-14
1.97
50
GC-SFFX-1212
54760-1212 5/8 15.90 1 1/16-14
2.17
55
SAE 45 Flare, Female, Swivel, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFFX45-0606 54763-0606 5/16 7.90 5/8-18 0.79
20
2.17
55
GC-SFFX45-0608 54763-0608 5/16 7.90 3/4-16 0.79
20
2.17
55
GC-SFFX45-0806 54763-0806 13/32 10.30 5/8-18 0.79
20
2.17
55
GC-SFFX45-0808 54763-0808 13/32 10.30 3/4-16 0.79
20
2.36
60
GC-SFFX45-1008 54763-1008 1/2 12.70 3/4-16 0.79
20
2.36
60
GC-SFFX45-1010 54763-1010 1/2 12.70 7/8-14 0.87
22
2.36
60
GC-SFFX45-1210 54763-1210 5/8 15.90 7/8-14 0.87
22
2.36
60
GC-SFFX45-1212 54763-1212 5/8 15.90 1 1/16-14 0.87
22
2.36
60
Same as GC-OTM with
134a Valve
One Source, One System, One Solution.
www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 27 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
