O-Ring Tube, Female, Swivel, R12 Valve, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF12V90-0606 54655-0606 5/16 7.90 5/8-18 1.26 32 1.10 28 1/4 6.35
GC-OTF12V90-0808 54655-0808 13/32 10.30 3/4-16 1.42 36 1.42 36 1/4 6.35
GC-OTF12V90-1010 54655-1010 1/2 12.70 7/8-14 1.65 42 1.81 46 1/4 6.35
GC-OTF12V90-1210 54655-1210 5/8 15.90 7/8-14 1.50 38 1.50 38 1/4 6.35
O-Ring Tube, Female, Swivel, R134a Valve
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF134V-0606 54660-0606 5/16 7.90 5/8-18 1.06 27 0.63 16
GC-OTF134V-0808 54660-0808 13/32 10.30 3/4-16 1.22 31 0.63 16
GC-OTF134V-1010 54660-1010 1/2 12.70 7/8-14 1.61 41 0.51 13
GC-OTF134V-1210 54660-1210 5/8 15.90 7/8-14 1.61 41 0.51 13
GC-OTF134V-1212 54660-1212 5/8 15.90 1 1/16-14 1.73 44 0.51 13
GC-OTF134VHS-1010 54675-1010 5/8 15.90 7/8-14 1.61 41 0.63 16
O-Ring Tube, Female, Swivel, R134a Valve, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF134V45-0606 54663-0606 5/16 7.90 5/8-18 0.55 14 0.98 25 0.63 16
GC-OTF134V45-0808 54663-0808 13/32 10.30 3/4-16 0.59 15 1.02 26 0.63 16
GC-OTF134V45-1010 54663-1010 1/2 12.70 7/8-14 0.67 17 1.06 27 0.51 13
GC-OTF134V45-1210 54663-1210 5/8 15.90 7/8-14 0.67 17 1.06 27 0.51 13
GC-OTF134V45-1212 54663-1212 5/8 15.90 1 1/16-14 0.94 24 1.77 45 0.51 13
O-Ring Tube, Female, Swivel, R134a Valve, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF134V90-0606 54665-0606 5/16 7.90 5/8-18 1.26 32 1.10 28 0.63 16
GC-OTF134V90-0806 54665-0806 13/32 10.30 5/8-18 1.26 32 1.10 28 0.63 16
GC-OTF134V90-0808 54665-0808 13/32 10.30 3/4-16 1.42 36 1.42 36 0.63 16
GC-OTF134V90-1010 54665-1010 1/2 12.70 7/8-14 1.65 42 1.81 46 0.51 13
GC-OTF134V90-1210 54665-1210 5/8 15.90 7/8-14 1.65 42 1.81 46 0.51 13
GC-OTF134V90-1212 54665-1212 5/8 15.90 1 1/16-14 1.77 45 2.05 52 0.51 13
Same as GC-OTF 90
with R12 Valve
One Source, One System, One Solution. www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 25 –
COOL CLIP ™ FITTINGS
For use with GALAXY® G4890 Hose
