O-Ring Insert Male, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OIM45-0606 54503-0606 5/16 7.90 5/8-18 0.75 19 0.83 21
GC-OIM45-0808 54503-0808 13/32 10.30 3/4-16 0.94 24 0.94 24
GC-OIM45-1010 54503-1010 1/2 12.70 7/8-14 1.26 32 1.26 32
GC-OIM45-1212 54503-1212 5/8 15.90 1 1/16-14 1.38 35 1.42 36
O-Ring Insert Male, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OIM90-0606 54505-0606 5/16 7.90 5/8-18 1.38 35 1.77 45
GC-OIM90-0808 54505-0808 13/32 10.30 3/4-16 1.73 44 1.26 32
GC-OIM90-1010 54505-1010 1/2 12.70 7/8-14 2.17 55 1.97 50
GC-OIM90-1210 54505-1210 5/8 15.90 7/8-14 2.17 55 1.97 50
GC-OIM90-1212 54505-1212 5/8 15.90 1 1/16-14 2.76 70 1.97 50
O-Ring Insert Male, Bulkhead
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OIMB-0606 54515-0606 5/16 7.90 5/8-18 2.80 71
GC-OIMB-0808 54515-0808 13/32 10.30 3/4-16 2.80 71
GC-OIMB-1010 54515-1010 1/2 12.70 7/8-14 2.80 71
O-Ring Insert Male, Bulkhead, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OIMB90-0606 54520-0606 5/16 7.90 5/8-18 2.13 54 1.61 41
GC-OIMB90-0808 54520-0808 13/32 10.30 3/4-16 2.44 62 1.73 44
GC-OIMB90-1010 54520-1010 5/8 15.90 7/8-14 2.52 64 2.01 51
– 22 –
COOL CLIP ™ FITTINGS
For use with GALAXY® G4890 Hose
