O-Ring Tube, Male, Swivel, R134a Valve, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTM134V90-1010 50735-1010 1/2 12.70 7/8-18 2.13 54 2.36 60 0.51 13
AC-OTM134V90-1210 50735-1210 5/8 15.90 7/8-18 2.13 54 2.36 60 0.51 13
SAE 45 Flare, Female, Swivel
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-SFFX-0606 50760-0606 5/16 7.90 5/8-18 1.38 35
AC-SFFX-0608 50760-0608 5/16 7.90 3/4-16 1.18 30
AC-SFFX-0806 50760-0806 13/32 10.30 5/8-18 1.18 30
AC-SFFX-0808 50760-0808 13/32 10.30 3/4-16 1.18 30
AC-SFFX-1008 50760-1008 1/2 12.70 3/4-16 1.50 38
AC-SFFX-1010 50760-1010 1/2 12.70 7/8-14 1.50 38
AC-SFFX-1210 50760-1210 5/8 15.90 7/8-14 1.73 44
AC-SFFX-1212 50760-1212 5/8 15.90 1 1/16-14 1.73 44
SAE 45 Flare, Female, Swivel, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-SFFX45-0606 50763-0606 5/16 7.90 5/8-18 0.55 14 0.83 21
AC-SFFX45-0608 50763-0608 5/16 7.90 3/4-16 0.63 16 0.94 24
AC-SFFX45-0806 50763-0806 13/32 10.30 5/8-18 0.63 16 0.94 24
AC-SFFX45-0808 50763-0808 13/32 10.30 3/4-16 0.63 16 0.94 24
AC-SFFX45-1008 50763-1008 1/2 12.70 3/4-16 0.87 22 1.26 32
AC-SFFX45-1010 50763-1010 1/2 12.70 7/8-14 0.87 22 1.26 32
AC-SFFX45-1210 50763-1210 5/8 15.90 7/8-14 0.98 25 1.50 38
AC-SFFX45-1212 50763-1212 5/8 15.90 1 1/16-14 0.98 25 1.50 38
SAE 45 Flare, Female, Swivel, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-SFFX90-0606 50765-0606 5/16 7.90 5/8-18 1.06 27 1.06 27
AC-SFFX90-0608 50765-0608 5/16 7.90 3/4-16 1.26 32 1.26 32
AC-SFFX90-0806 50765-0806 13/32 10.30 5/8-18 1.26 32 1.26 32
AC-SFFX90-0808 50765-0808 13/32 10.30 3/4-16 1.26 32 1.26 32
AC-SFFX90-1008 50765-1008 1/2 12.70 3/4-16 1.50 38 1.50 38
AC-SFFX90-1010 50765-1010 1/2 12.70 7/8-14 1.50 38 1.50 38
AC-SFFX90-1210 50765-1210 5/8 15.90 7/8-14 1.50 38 1.73 44
AC-SFFX90-1212 50765-1212 5/8 15.90 1 1/16-14 1.50 38 1.73 44
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
