C-21
ASTM D2000 Line Callouts
Benefits
Wide range of natural and synthetic rubbers
¦
Incompressible—can be deformed, depending on
durometer and cross section, but can never be reduced
in volume
¦
Extensible—can be assembled over a projection or
shoulder and snap tightly within a groove
¦
Highly impermeable—can serve as a tight barrier
against the passage of gases or liquids
¦
Elastic—little flange pressure required to effect intimate
contact with gasket, allowing it to move with the flange
surfaces, always maintaining a seal
¦
Complies with RMA (Rubber Manufacturing
Association)
Standard Commercial
Tolerances
Premium-Grade and Reinforced Rubber and
Diaphragm Gasketing
Nominal Thickness
Fractions Decimals
Tolerance
under 1/32"
0.031"
±0.010"
1/32" up to 1/16" 0.031" up to 0.062"
±0.012"
1/16" up to 1/8"
0.062" up to 0.125"
±0.016"
1/8" up to 3/16"
0.125" up to 0.187"
±0.020"
3/16" up to 3/8"
0.187" up to 0.375"
±0.031"
3/8" up to 9/16"
0.375" up to 0.562"
±0.047"
9/16" up to 3/4"
0.562" up to 0.750"
±0.063"
3/4" up to 1"
0.750" up to 1.00"
±0.093"
1" and up
1.00" and up
±10%
WARNING:
Properties/applications shown throughout this brochure are typical. Your specific applica-
tion should not be undertaken without independent study and evaluation for suitability.
For specific application recommendations consult Garlock. Failure to select the proper
sealing products could result in property damage and/or serious personal injury.
Performance data published in this brochure has been developed from field testing,
customer field reports and/or in-house testing.
While the utmost care has been used in compiling this brochure, we assume no respon-
sibility for errors. Specifications subject to change without notice. This edition cancels
all previous issues. Subject to change without notice.
GARLOCK is a registered trademark for packings, seals, gaskets, and other products
of Garlock.
Style
ASTM Line Callout
22
2AA810A13F16EA14
7797
4BC815A14E014E034G21
7986
6BC620E014E034G21
8314
4AA610A13B13B33, BA610A14B13
9064
2BE620A14E014E034F17
9122
5BG620A14B14EA14E014E034
9518
2HK710B3721
9780
2HK715A1-10 B37
Gaskets
Garlock
®
Questions? Call Gasket Applications
Engineering at 1-800-448-6688.
