Page 24 - FlexitallicCatalog2010

25
STYLE CG & CGI TO SUIT JIS FLANGES PRESSURE RATING 1OKgf/cm2 – 16-20Kgf/cm2
TABLE
16
DIMENSIONS IN mm.
PRESSURE RATING 10Kgf/cm 2
Inner Sealing Element Centering
Nom. Ring Ring
Pipe Inside Inside Outside Outside
Size Dia. Dia. Dia. Dia.
10 – 24 37 52
15 – 28 41 57
20 – 34 47 62
25 – 40 53 74
32 – 51 67 84
40 – 57 73 89
50 – 69 89 104
65 – 87 107 124
80 – 98 118 134
90 – 110 130 144
100 – 123 143 159
125 – 148 173 190
150 – 174 199 220
175 – 201 226 245
200 – 227 252 270
225 – 252 277 290
250 – 278 310 332
300 – 329 361 377
350 – 366 406 422
400 – 417 457 484
450 – 468 518 539
500 – 518 568 594
550 – 569 619 650
600 – 620 670 700
PRESSURE RATING 16 to 20Kgf/cm2
Inner Sealing Element Centering
Nom. Ring Ring
Pipe Inside Inside Outside Outside
Size Dia. Dia. Dia. Dia.
10 18 24 37 52
15 22 28 41 57
20 28 34 47 62
25 34 40 53 74
32 43 51 67 84
40 49 57 73 89
50 61 69 89 104
65 77 87 107 124
80 89 99 119 140
90 102 114 139 150
100 115 127 152 165
125 140 152 177 202
150 166 182 214 237
175 – – – –
200 217 233 265 282
225 – – – –
250 268 288 328 354
300 319 339 379 404
350 356 376 416 450
400 407 432 482 508
450 458 483 533 573
500 508 533 583 628
550 559 584 634 684
600 610 635 685 734
STYLE CG & CGI TO SUIT JIS FLANGES PRESSURE RATING 3OKgf/cm2 - 63Kgf/cm2
TABLE
17
DIMENSIONS IN mm.
PRESSURE RATING 40Kgf/cm2
Inner Sealing Element Centering
Nom. Ring Ring
Pipe Inside Inside Outside Outside
Size Dia. Dia. Dia. Dia.
10 15 21 34 59
15 18 24 37 64
20 23 29 42 69
25 29 35 48 79
32 38 44 60 89
40 43 51 67 100
50 55 63 79 114
65 68 78 98 140
80 80 90 110 150
90 92 102 127 162
100 104 116 141 182
125 128 140 165 224
150 153 165 197 265
200 202 218 250 315
250 251 271 311 378
300 300 320 360 434
350 336 356 396 479
400 383 403 453 531
PRESSURE RATING 63Kgf/cm2
Inner Sealing Element Centering
Nom. Ring Ring
Pipe Inside Inside Outside Outside
Size Dia. Dia. Dia. Dia.
10 15 21 34 64
15 18 24 37 69
20 23 29 42 75
25 29 35 48 80
32 38 44 60 90
40 43 51 67 107
50 55 63 79 125
65 68 78 98 152
80 80 90 110 162
90 92 102 127 179
100 104 116 141 194
125 128 140 165 235
150 153 165 197 275
200 202 218 250 328
250 251 271 311 394
300 300 320 360 446
350 336 356 396 488
400 383 403 453 545
PRESSURE RATING 30Kgl/cm2
Inner Sealing Element Centering
Nom. Ring Ring
Pipe Inside Inside Outside Outside
Size Dia. Dia. Dia. Dia.
10 18 24 37 59
15 22 28 41 64
20 28 34 47 69
25 34 40 53 79
32 43 51 67 89
40 49 57 73 100
50 61 69 89 114
65 68 78 98 140
80 80 90 110 150
90 92 102 127 162
100 104 116 141 172
125 128 140 165 207
150 153 165 197 249
200 202 218 250 294
250 251 271 311 360
300 300 320 360 418
350 336 356 396 463
400 383 403 453 524
