Figure 3: Compression Sleeves
Also available with spherical washer
t
Metric Conversion: Nominal I.D.: in. x 25 = mm; Dimensions: in. x 25.4 = mm; Pressure: PSIG x .069 = Bar
Number of Control Units is dependent upon pressure and temperature of system. Refer to Fluid Sealing
Association's - REJ Division Manual, Appendix C (Sixth Edition) for
minimum
number of control units (per
pressure rating) required for a rubber expansion joint when specified.
Values listed in this table are maximum values based on PROCO'S engineering data.
1. Control rod plate O.D. installed dimension is based on a
maximum
O.D. PROCO would supply. (Figures 2 and 3.)
2. Plate thickness is based on a
maximum
width PROCO would use to design a control rod plate.
3. Control rod diameter is based on a
maximum
diameter PROCO would use to design a control rod.
COMPRESS I ON SLEEVES
Table 5: Control Unit Plate Detail
See Notes Below
NOMINAL SIZE
Inch / (mm)
CONTROL ROD
1
PLATE O.D.
Inch / (mm)
MAXIMUM
2
PLATE THK
Inch / (mm)
MAXIMUM
3
ROD DIAMETER
Inch / (mm)
1
(25)
8.375
(212.7)
0.625
(15.9)
0.625
(15.9)
1.25
(32)
8.750
(222.3)
0.625
(15.9)
0.625
(15.9)
1.5
(40)
9.125
(231.8)
0.375
(9.5)
0.625
(15.9)
2
(50)
10.125
(257.2)
0.500
(12.7)
0.625
(15.9)
2.5
(65)
11.125
(282.6)
0.500
(12.7)
1.000
(25.4)
3
(80)
11.625
(295.3)
0.500
(12.7)
1.000
(25.4)
3.5
(90)
12.625
(320.7)
0.625
(15.9)
1.000
(25.4)
4
(100)
13.125
(333.4)
0.625
(15.9)
1.000
(25.4)
5
(125)
14.125
(358.8)
0.500
(12.7)
1.000
(25.4)
6
(150)
15.125
(384.2)
0.500
(12.7)
1.000
(25.4)
8
(200)
19.125
(485.8)
0.625
(15.9)
1.000
(25.4)
10
(250)
21.625
(549.3)
0.750
(19.1)
1.000
(25.4)
12
(300)
24.625
(625.5)
0.750
(19.1)
1.000
(25.4)
14
(350)
26.625
(676.3)
0.750
(19.1)
1.000
(25.4)
16
(400)
30.125
(765.2)
1.000
(25.4)
1.250
(31.8)
18
(450)
31.625
(803.3)
1.000
(25.4)
1.250
(31.8)
20
(500)
34.125
(866.8)
1.000
(25.4)
1.250
(31.8)
22
(550)
36.125
(917.6)
1.000
(25.4)
1.250
(31.8)
24
(600)
38.625
(981.1)
1.000
(25.4)
1.250
(31.8)
26
(650)
40.875
(1038.2)
1.000
(25.4)
1.250
(31.8)
28
(700)
44.125
(1120.8)
1.250
(31.8)
1.500
(38.1)
30
(750)
46.375
(1177.9)
1.500
(38.1)
1.500
(38.1)
32
(800)
49.375
(1254.1)
1.250
(31.8)
1.500
(38.1)
34
(850)
52.375
(1330.3)
1.500
(38.1)
1.750
(44.5)
36
(900)
54.625
(1387.5)
1.750
(44.5)
1.750
(44.5)
38
(950)
57.375
(1457.3)
1.500
(38.1)
1.750
(44.5)
40
(1000)
58.375
(1482.7)
1.500
(38.1)
1.500
(38.1)
42
(1050)
61.625
(1565.3)
1.500
(38.1)
1.750
(44.5)
44
(1100)
63.875
(1622.4)
1.500
(38.1)
1.750
(44.5)
46
(1150)
65.875
(1673.2)
1.500
(38.1)
1.750
(44.5)
48
(1200)
68.125
(1730.4)
1.750
(44.5)
1.750
(44.5)
50
(1250)
70.375
(1787.5)
1.500
(38.1)
1.750
(44.5)
52
(1300)
73.625
(1870.1)
1.750
(44.5)
2.000
(50.8)
54
(1350)
75.875
(1927.2)
2.000
(50.8)
2.000
(50.8)
56
(1400)
78.375
(1990.7)
2.000
(50.8)
2.000
(50.8)
58
(1450)
80.625
(2047.9)
2.000
(50.8)
2.000
(50.8)
60
(1500)
82.625
(2098.7)
2.000
(50.8)
2.000
(50.8)
66
(1650)
89.625
(2276.5)
2.000
(50.8)
2.000
(50.8)
68
(1700)
91.875
(2333.6)
2.000
(50.8)
2.000
(50.8)
72
(1800)
96.125
(2441.6)
2.000
(50.8)
2.000
(50.8)
78
(2000)
103.125
(2619.4)
2.000
(50.8)
2.250
(57.2)
84
(2150)
109.875
(2790.8)
2.250
(57.2)
2.250
(57.2)
90
(2300)
117.125
(2975.0)
2.500
(63.5)
2.500
(63.5)
96
(2450)
124.625
(3165.9)
2.750
(69.9)
2.750
(69.9)
102
(2500)
131.375
(3336.5)
2.500
(63.5)
2.750
(69.9)
108
(2750)
138.125
(3508.4)
2.500
(63.5)
2.750
(69.9)
120
(3050)
152.125
(3864.0)
2.500
(63.5)
3.000
(76.2)
132
(3350)
166.625
(4232.2)
2.500
(63.5)
3.250
(82.6)
144
(3650)
180.750
(4591.1)
2.500
(63.5)
3.500
(88.9)
Series 230
Page 13 of 16
