400 SERIES
CROSS SECTION
400 SERIES FENDER
FITTED WITH
BRACKETS WELDED
TO DOCK OR SHIP
CROSS SECTION
400 SERIES
FENDER BOLTED
THROUGH DOCK
WING TYPE O-BORE
Designed for easy attachment to vessels and docks.
Drill and bolt fender to structure using the integral wings.
Eliminates need for mounting holes on the facing. Offered in
three EPDM colors: black, non-marking grey and white.
CODE NO.
DURAMAX
®
BASE
BASE
OUTSIDE
BORE
WT./FT.
LENGTH
PART NO.
WIDTH (W)
THICKNESS (BT)
DIAM. (D)
DIAM.
UP TO
DB-404
802040401
4”
1/2”
2 1/2”
1”
3.5 LBS.
60 FT.
DB-405
802040501
5”
1/2”
2 1/2”
1”
4 LBS.
60 FT.
DB-406
802040601
6”
3/4”
3”
1”
5.3 LBS.
60 FT.
DB-407
802040701
6 1/2”
1”
4”
2”
7 LBS.
60 FT.
DB-408
802040801
6 1/2”
1”
4”
1”
8.9 LBS.
60 FT.
DB-409
802040901
9”
1 1/2”
6”
3”
15.3 LBS.
20 FT.
DB-409A
802040911
9”
1 1/2”
6”
2”
17.4 LBS.
20 FT.
DB-410
802041001
9 1/2”
1 1/2”
6”
2”
17.7 LBS.
20 FT.
DB-412
802041201
12”
2”
8”
4”
27 LBS.
20 FT.
DB-416
802041601
16”
2 1/2”
10”
4”
47.5 LBS.
20 FT.
DB-418
802041801
18”
3”
12”
6”
61 LBS.
20 FT.
B
BT
W
D
13
APE / KEY BORE D-SHAPE / KEY BOR
E
WING TYPE/O- BORE
D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE
