281
DPL410
877.963.4966 • www.dixonvalve.com
S
Hose Size NPT Size
Zinc Plated Steel
Opt
Qty
Part #
Price/E
1/4"
1/4"
1/4"
3/8"
3/8"
3/8"
1/2"
1/2"
1/2"
1/2"
3/4"
3/4"
3/4"
1"
1"
1/8"
1/4"
3/8"
1/4"
3/8"
1/2"
1/4"
3/8"
1/2"
3/4"
1/2"
3/4"
1"
3/4"
1"
3501
3502
3504
3505
3506
3508
3509
3510
3512
3511
3513
3514
3515
3516
3518
$6.40
5.15
6.70
6.15
5.85
8.50
7.00
6.80
8.50
11.30
12.15
11.00
20.20
19.00
16.40
100
100
100
100
100
100
100
100
100
50
50
50
25
25
25
Male Nipple
(hose shank x male NPT)
Hose Size NPT Size
Zinc Plated Steel
Opt
Qty
Part #
Price/E
1/4"
3/8"
3/8"
1/2"
1/2"
3/4"
1/4"
1/4"
3/8"
3/8"
1/2"
3/4"
3542
3545
3546
3550
3552
3554
$9.00
10.30
10.70
10.55
12.50
17.40
100
50
50
100
50
50
Female Nipple
(hose shank x female NPT)
Steel 3500 Nipples with Ferrules
Exclusive interlocking ferrule can be crimped or swaged to achieve maximum coupling sealing and retention. The 3500 steel
nipples with ferrules have a low profile, streamline appearance. For crimp dimensions see page 634.
•
zinc plated steel 3500 nipple with carbon steel ferrule
•
can be crimped or swaged-on
•
rated to
600 PSI
working pressure at ambient
temperature (70°F)
•
for air and water service only
Size
Hose OD
Steel
From:
To:
Part #
Price/E
1/2"
3/4"
1"
54/64"
1-10/64"
1-30/64"
58/64"
1-14/64"
1-34/64"
3512WF
3514WF
3518WF
$19.35
19.90
20.70
The Importance of Whip Hose
The constant vibration created by air tools, like air drills and pavement breakers, is destructive to air hose
couplings, especially the quick-acting type. To provide protection against coupling breakage and related hazards,
Dixon recommends the use of a whip hose. To construct a whip hose, connect one end of a short (3' to 10')air hose
to the air tool using a 3500 type steel nipple. Connect the other end of the hose to the air supply using the standard
quick-acting coupling. The heat-treated 3500 nipple will withstand vibration far better than the standard coupling and
provide a safer connection. The whip hose should remain permanently connected to the tool.
