DPL410
877.963.4966 • www.dixonvalve.com
A
•
0-125 PSIG adjusting range
•
5 micron reusable element
•
5 oz. bowl
•
self-relieving standard
•
diaphragm operated
•
quick-disconnect bowl guard with integral plastic bowl and
safety latch standard
•
Two 1/4" gauge ports are provided in either side of the
regulator body for installation of a gauge or to use as an
additional outlet port. Plug unused port(s).
•
supplied with GC230 gauge
•
maximum operating conditions:
transparent bowl:
150 PSIG
(10.3 bar) and
32°F
to
125°F
(0°C to 52°C)
metal bowl:
200 PSIG
(13.8 bar) and
32°F
to
150°F
(0°C to
65.5°C)
FRL's are designed for air service only, unless otherwise indicated.
SCFM ratings at 100 PSIG inlet pressure.
Over-under units are space savers and provide for installation in tight areas. One common inlet/outlet for both filter and regulator
saves on piping costs.
with guard
•
0-125 PSIG adjusting range
•
5 micron element
•
4 oz. bowl
•
self-relieving standard
•
spring-loaded diaphragm
•
Two ¼" gauge ports located on the front and rear faces of
the body. These ports may be used as additional regulated
ports or for pressure gauges. Plug unused port(s).
•
supplied with GC230 gauge
•
maximum operating conditions:
transparent bowl:
150 PSIG
(10.3 bar) and
32°F
to
125°F
(0°C to 52°C)
metal bowl:
250 PSIG
(17.2 bar) and
32°F
to
150°F
(0°C to
65.5°C)
•
To increase regulated pressure, pull adjusting knob and turn
clockwise. To reduce pressure, turn knob counter clockwise.
To lock knob, push down.
2.36 (60)
10.00 (25
4)
3.66 (93)
1.60 (41)
Bowl Removal
Clearance
with metal bowl
See pages 220-221 for filter/regulator accessories.
Size SCFM
With Transparent Bowl and Guard
With Metal Bowl with Sight Glass
Automatic Drain
Manual Drain
Automatic Drain
Manual Drain
Part #
Price/E
Part #
Price/E
Part #
Price/E
Part #
Price/E
1/4"
3/8"
1/2"
64.0
70.0
70.0
CB6-02AG
CB6-03AG
CB6-04AG
$244.55
244.55
244.55
CB6-02MG
CB6-03MG
CB6-04MG
$191.90
191.90
191.90
CB6-02AGMB
CB6-03AGMB
CB6-04AGMB
$261.25
261.25
261.25
CB6-02MGMB
CB6-03MGMB
CB6-04MGMB
$208.55
208.55
208.55
Size SCFM
With Transparent Bowl and Guard
With Metal Bowl with Sight Glass
Automatic Drain
Manual Drain
Automatic Drain
Manual Drain
Part #
Price/E
Part #
Price/E
Part #
Price/E
Part #
Price/E
1/4"
3/8"
1/2"
88
117
121
B18-02AG
B18-03AG
B18-04AG
$224.70
224.70
224.70
B18-02MG
B18-03MG
B18-04MG
$172.00
172.00
172.00
B18-02AGMB
B18-03AGMB
B18-04AGMB
$236.60
236.60
236.60
B18-02MGMB
B18-03MGMB
B18-04MGMB
$186.30
186.30
186.30
