111
DPL410
877.963.4966 • www.dixonvalve.com
A
Dix-Lock Cap
Body
Size
Brass
Opt
Qty
Steel
Opt
Qty
Part # Price/E
Part # Price/E
½"
QBCAP
$24.56
25
QMCAP
$21.39
25
Body Size
Steel
Opt Qty
Part #
Price/E
½"
QM0
$60.35
25
Dix-Lock Quick-Acting Couplings with Ferrules
•
rated to
300 PSI
working pressure at ambient
temperature (70°F)
•
for crimp recommendations see page 634
•
also available in stainless steel, contact the factory for
further information
Body
Size
Hose
ID
Hose OD
Material
Part # Price/E
Male Head
From:
To:
1/2"
1/2"
1/2"
1/2"
1/2"
3/4"
1/2"
3/4"
27/32"
1-5/32"
27/32"
1-5/32"
1-1/32"
1-11/32"
1-1/32"
1-11/32"
plated steel
plated steel
brass
brass
QM3WF
QM4WF
QB3WF
QB4WF
$30.10
30.10
45.50
45.50
Body
Size
Hose
ID
Hose OD
Material
Part # Price/E
Female Head
From:
To:
1/2"
1/2"
1/2"
1/2"
1/2"
3/4"
1/2"
3/4"
27/32"
1-5/32"
27/32"
1-5/32"
1-1/32"
1-11/32"
1-1/32"
1-11/32"
plated steel
plated steel
brass
brass
QM22WF
QM23WF
QB22WF
QB23WF
$25.80
25.80
34.85
34.85
Body
Size
Hose
ID
Hose OD
Material
Part # Price/E
Male Locking Head
From:
To:
1/2"
1/2"
1/2"
1/2"
1/2"
3/4"
1/2"
3/4"
27/32"
1-5/32"
27/32"
1-5/32"
1-1/32"
1-11/32"
1-1/32"
1-11/32"
plated steel
plated steel
brass
brass
QM33WF
QM44WF
QB33WF
QB44WF
$38.40
38.40
48.90
48.90
