Valves
Dixon Powhatan 2007
1-6
1-800-355-1991
Brass Angle Hose Valves
18-157 / 18-158
•
Cast brass with an aluminum hand wheel
•
U/L listed and FM Approved
•
New York City Board of Standards and Appeals approved
•
For use up to
300 PSI
Dixon
Part #
AVF150
AVF250
Inlet
Female NPT
1½"
2½"
Powhatan
Part #
18-158-00004
18-158-00055
Outlet
Female NPT
1½"
2½"
Angle Valves
Dixon
Part #
AV150
AV150NYFD
AV150S
AV150T
AV250
AV250NYC
AV250NYFD
AV250PITT
AV250S
Inlet
Female NPT
1½"
1½"
1½"
1½"
2½"
2½"
2½"
2½"
2½"
Powhatan
Part #
18-157-00010
18-157-00016
18-157-00005
18-157-00329
18-157-00388
18-157-00391
18-157-00412
18-157-00387
18-157-00426
Outlet
Male
1½" NST
1½" NYFD
1½" NPSH
1½" NPT
2½" NST
2½" NYC
2½" NYFD
2½" PITT
2½" NPSH
Replacement Parts
Dixon
Part #
AV150-W
AV250-W
AV150-N
AV250-N
AV150-RBR
AV250-RBR
Description
Replacement handwheel for 1½" valve
Replacement handwheel for 2½" valve
Handwheel nut for 1½" valve
Handwheel nut for 2½" valve
Valve seal rubber for 1½" valve
Valve seal rubber for 2½" valve
Powhatan
Part #
46-019-01455
46-019-01456
46-011-00948
46-011-00947
46-012-01415
46-012-01416
Size
Dimensions (
inches
)
A
B
C / closed
2 11/64"
3 3/16"
1½"
2½"
C / open
D
2 7/32"
3 3/16"
6 5/8"
9 1/4"
7 21/32"
11"
3 3/4"
5"
Weight
(
lbs.
)
4 lbs.-8 oz.
9 lbs.-5 oz.
F
2 13/16"
3 19/32"
