#1
2 Ply 150 1/32 x Bare Back Grade 2
Part Number: 20027202
This belt specifcation fts light-duty applications such as package handling, sorting lines, and
applications requiring minimum tensions with no need to resist heavy impact. Standard grade
rubber covers resist abrasion and weathering in nonoily applications. Used as an economical
general purpose belt and popular in many agricultural applications, including potato conveying
and transport on slider beds.
Temp. Range:
-25°F to 225°F.
Thickness:
5/32".
Weight:
.075 piw.
Min. Pulley Diameter:
4".
Recommended Fasteners:
#2 Hook, #125 Staple, #15 Alligator.
#2
2 Ply 150 1/32 x 1/32 Grade 2
Part Number: 20027301
This belt specifcation fts light-duty applications such as package handling, sorting lines,
and applications requiring minimum tensions with no need to resist heavy impact. Standard
grade rubber covers resist abrasion and weathering in nonoily applications, including potato
conveying and transport in troughing conveyors.
Temp. Range:
-25°F to 225°F.
Thickness:
13/64".
Weight:
.085 piw.
Min. Pulley Diameter:
6".
Recommended Fasteners:
#3 Hook, #187 Staple, #25 Alligator.
#2A
2 Ply 150 1/16 x Bare Back Grade 2
Part Number: 20026910
Excellent light-duty conveyor belt with a medium thick abrasion resistant cover. Often used in
agricultural applications and in bunk feeders where the belt slides on fat pan surfaces. Good
selection for package handling applications where smooth surfaces are permissible. SBR
cover provides excellent fex life and resistance to abrasion, making it a good buy for most
conveyor applications.
Temp. Range:
-25°F to 225°F.
Thickness:
3/16".
Weight:
.105 piw.
Min. Pulley Diameter:
6".
Recommended Fasteners:
#2 Hook, #125 Staple, #20 Alligator.
#3
2 Ply 150 1/8 x 1/32 Grade 2
Part Number: 20000010
Excellent light-duty conveyor belt with medium thick abrasion resistant covers. Often used
in agricultural applications and for sand conveying in the sand and gravel industry. Good
selection for other light-duty applications on troughing conveyors. SBR covers provide
excellent fex life and resistance to abrasion, making it a good buy for most conveyor
applications.
Temp. Range:
-25°F to 225°F.
Thickness:
1/4".
Weight:
.138 piw.
Min. Pulley Diameter:
8".
Recommended Fasteners:
#140 Solid Plate, #187 Staple,
#375 Bolt On, #R2 Rivet.
#4
2 Ply 150 1/8 x 1/16 Grade 2
Part Number: 20003990
Excellent light-duty conveyor belt with medium thick abrasion resistant cover. Often used in
agricultural applications and for conveying pea gravel in the sand and gravel industry. Good
selection for other light-duty applications on trough conveyors. SBR covers provide excellent
fex life and resistance to abrasion, making it a good buy for most conveyor applications.
Temp. Range:
-25°F to 225°F.
Thickness:
9/32".
Weight:
.154 piw.
Min. Pulley Diameter:
10".
Recommended Fasteners:
#140 Solid Plate, #375 Bolt On, #R2
Rivet.
#6A
2 Ply 220 1/8 x Bare Back Grade 2
Part Number: 20029525
Excellent medium duty conveyor belt with moderately thick abrasion resistant top cover. Often
used in bunk feeders, where smooth surfaces are permissible, wood product, and agricultural
applications. SBR cover provides excellent fex life and resistance to abrasion, making it a
good buy for most conveyor applications.
Temp. Range:
-25°F to 225°F.
Thickness:
1/4".
Weight:
.145 piw.
Min. Pulley Diameter:
10".
Recommended fasteners:
#140 Solid Plate, #187 Staple, #375
Bolt On, #R2 Rivet.
