19
#64A
PVC 100 Black Cover x Friction Surface
Part Number: 20035498
This thin, strong, yet fexible belt is ideal for general purpose conveying on slider bed
conveyors. Used mostly on light-duty conveying applications of small products.
Temp. Range:
20°F to 180°F.
Thickness:
7/64".
Weight:
.065 piw.
Min. Pulley Diameter:
2".
Recommended Fasteners:
#25LP Hook, #62 Staple,
#7 Alligator.
#64B
PVC 120 Black Friction Surface x Brushed Bottom
Part Number: 20035508
Proven belt for long wearing, high performance, problem free package handling applications.
Friction surfaces on both top and bottom permit belt to move while package remains stopped
in accumulator. Ideal for a variety of roller/slider bed applications. Characteristics include low
stretch, high strength, good fastener retention, with superior rip, tear, and gouge resistance.
Temp. Range:
20°F to 180°F.
Thickness:
1/8".
Weight:
.050 piw.
Min. Pulley Diameter:
2".
Recommended Fasteners:
#1 Hook; #125 Staple; #15 Alligator.
#219
PVC 120 Green Roughtop x Friction Surface
Part Number: 20034520
This roughtop textured PVC belt has a non-marking/non-skid surface that enables packages,
boxes, cases, and other products to be conveyed on both inclines and declines. Uni-ply
construction and PVC compounds combine properties for high traction and low stretch.
Temp. Range:
20°F to 180°F.
Thickness:
13/64".
Weight:
.100 piw.
Min. Pulley Diameter:
2-1/2".
Recommended Fasteners:
#1 Hook, #125 Staple,
#15 Alligator.
#65B
PVC 100 Black Cover x Friction Surface LT
Part Number: 20035499
This specially compounded PVC belt has low temperature resistance. Thin, yet strong and
fexible, this belt is ideal in many agricultural applications and for general purpose conveying.
Temp. Range:
-20°F to 180°F.
Thickness:
7/64".
Weight:
.070 piw.
Min. Pulley Diameter:
2".
Recommended Fasteners:
#1SP Hook, #62 Staple, #7 Alligator.
#65
PVC 120 Black Cover x Friction Surface
Part Number: 20035501
Proven belt for long wearing, high performance, problem free package handling applications.
Ideal for a variety of roller/slider bed applications. Characteristics include low stretch, high
strength, good fastener retention, with superior rip, tear, and gouge resistance.
Temp. Range:
20°F to 180°F.
Thickness:
9/64".
Weight:
.075 piw.
Min. Pulley Diameter:
2".
Recommended Fasteners:
#1 Hook, #125 Staple, #15 Alligator.
#61B
PVC 150 Black Roughtop x Friction Surface
Part Number: 20035509
This heavier duty roughtop textured PVC belt has a nonskid surface that enables packages,
boxes, cases, and other products to be conveyed on both inclines and declines. Solid woven
uni-ply construction and PVC compounds for high traction and performance.
Temp. Range:
20°F to 180°F.
Thickness:
13/64".
Weight:
.113 piw.
Min. Pulley Diameter:
3".
Recommended Fasteners:
#2 Hook, #20 Alligator, #125 Staple.
PVC - RMV Belt
