Pvc - RMV Belt
17
#56B
2 Ply 220 1/8 x Bare Back Durocleat Moderate Oil Resistance
Part Number: 20029602
The molded top cover profle is designed as a slittable chevron belt for heavier duty uses
that requires the ability to overcome the incline limitations of standard fat surface conveyor
belts. Other uses include carrying wood chips to surge piles, moving debris in the waste and
recycling industries, and in applications where higher belt operating tensions are required.
MOR compounds make belt resistant to moderately oily contaminants and the synthetic fabric
makes it strong and dimensionally stable. Comes in bare back for slider bed conveyors.
Temp. Range:
0°F to 250°F.
Thickness:
1/4".
Weight:
.185 piw.
Min. Pulley Diameter:
18".
Recommended Fasteners:
#190 Solid Plate, #375 Bolt On, #R5 Rivet.
#247
3 Ply 330 1/8 x Bare Back Durocleat Moderate Oil Resistance
Part Number: 20029607
The molded top cover profle is designed as a slittable chevron belt for heavier duty uses
that requires the ability to overcome the incline limitations of standard fat surface conveyor
belts. Other uses include carrying wood chips to surge piles, moving debris in the waste and
recycling industries, and in applications where higher belt operating tensions are required.
MOR compounds make belt resistant to moderately oily contaminants and the synthetic fabric
makes it strong and dimensionally stable. Comes in bare back for slider bed conveyors.
Temp. Range:
0°F to 250°F.
Thickness:
9/16".
Weight:
.225 piw.
Min. Pulley Diameter:
16".
Recommended Fasteners:
#190 Solid Plate, #550 Bolt On, #R5 Rivet.
#60
2 Ply 60 Matte PVC Checkout Counter x Bare Bottom
Part Number: 20032710
2 plies of polyester fabric (60 lb. piw) provide adequate strength for this thin belt commonly
used for retail check-out stands. Black PVC cover resists stains, cutting and gouges from
rough use. Matte cover is easily cleaned while back surface has low coeffcient of friction for
smooth operation on slider surfaces.
Temp. Range:
20°F to 180°F.
Thickness:
5/64".
Weight:
.047 piw.
Min. Pulley Diameter:
2".
Recommended Fasteners:
#25LP Hook, #1 Alligator.
#60B
3 Ply 150 Black RMV x Friction Surface
Part Number: 20032945
Excellent multiple purpose light-duty conveyor belt. Smooth 1/32". Used regularly on
assembly and packaging lines, and other applications requiring resistance to some oils
associated with products being moved. Carcass is fexible, yet strong. Cover resists oil,
grease, and animal fats.
Temperature range:
20°F to 180°F.
Thickness:
1/8".
Weight:
.080 piw.
Min. Pulley Diameter:
3".
Recommended Fasteners:
#1SP Hook, #62 Staple, #7 Alligator.
#60A
2 Ply 100 Black RMV x Friction Surface
Part Number: 20032940
Excellent all-purpose conveyor belt with a smooth 1/32" RMV top cover. Used regularly
on assembly and packaging lines, and other applications requiring resistance to some oils
associated with products being moved. Carcass is fexible, yet strong for stretch resistance.
Cover resists oil, grease, and animal fats.
Temp. Range:
20°F to 180°F.
Thickness:
7/64".
Weight:
.070 piw.
Min. Pulley Diameter:
1-1/2".
Recommended Fasteners:
#1SP Hook; #62 Staple;
#7 Alligator.
#61A
PVC 120 Black Roughtop x Friction Surface
Part Number: 20035506
This medium duty textured roughtop PVC belt has a nonskid surface that enables packages,
boxes, cases, and other products to be conveyed on both inclines and declines. Solid
woven uni-ply construction and PVC compounds combine properties for high traction
and performance. Synthetic, solid woven carcass has high strength and low stretch
characteristics.
Temp. Range:
20°F to 180°F.
Thickness:
11/64".
Weight:
.100 piw.
Min. Pulley Diameter:
2-1/2".
Recommended Fasteners:
#1 Hook, #125 Staple,
#15 Alligator.
Sl i ttable Chevron / PVC - RMV Belt
