METRIC FEMALE FITTINGS
Copyright © 2002-2007 40 BrakeQuip
HFMFX01
M10 x 1 Inverted Bulkhead 19mm 45mm V
THREAD SEAT MOUNT HEX OAL FITS
HFMFX02
M10 x 1.25 Inverted Bulkhead 19mm 45mm V
THREAD SEAT MOUNT HEX OAL FITS
HFMFX04
M10 x 1 DPS Bulkhead 19mm 45mm V
THREAD SEAT MOUNT HEX OAL FITS
5/8NF External Thread 5/8NF External Thread 5/8NF External Thread
BULKHEAD MOUNT
HFMF69
M10 x 1 Inverted Bolted 6.4mm 62mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF48
M10 x 1 Inverted Bolted 8.75mm 53mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF50
M10x1-(2) DPS Bolted 8/10mm 48mm US
THREAD SEAT MOUNT HOLE OAL FITS
HFMF18
M10x1-(2) Inverted Bolted 8.5mm 55mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF30
M12x1-10x1 Inverted Bolted 8.5mm 54mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF322
M10 x 1 Inverted Bolted M8 x 1.25 42mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF342
M10 x 1 Inverted Bolted 6.3mm 100mm A
THREAD SEAT MOUNT HOLE OAL FITS
HFMF343
M10 x 1 Inverted Bolted 6.3mm 100mm A
THREAD SEAT MOUNT HOLE OAL FITS
BOLT ON MOUNT
8.5mm Hole 8.5mm Hole 8.75mm Hole
8/10mm Hole 6.4mm Hole M8 x 1.25
6.3mm Hole 6.3mm Hole
