IMPERIAL FEMALE FITTINGS
Copyright © 2002-2007
30
BrakeQuip
A = Asian EU = European US = United States UNI = Universal V = Various
HFIF57
7/16NS x 2 Inverted Bolted 8/10mm 54mm US
THREAD SEAT MOUNT HOLE
OAL
FITS
HFIF66
3/8NF x 2 Inverted Bolted 12mm 93mm US
THREAD SEAT MOUNT HOLE
OAL
FITS
HFIF303
3/8NF-7/16NS Inverted Bolted 7/16"
70mm US
THREAD SEAT MOUNT HOLE
OAL
FITS
HFIF58
3/8NF x 2 Inverted Bolted 11.5mm 50mm US
THREAD SEAT MOUNT HOLE
OAL
FITS
HFIF59
3/8NF x 2 Inverted Bolted 12mm 100mm US
THREAD SEAT MOUNT HOLE
OAL
FITS
BOLT ON MOUNT
8/10mm Hole
12mm Hole
11.5mm Hole
12mm Hole
11.4mm Hole
HFIF03
1/2NF DPS
19mm 50mm US
THREAD SEAT MOUNT HEX OAL
FITS
HFIF06
1/2NF Inverted
17mm 38mm UNI
THREAD SEAT MOUNT HEX OAL
FITS
NO MOUNT
