Spring Driven Air/Water/Oil/Grease
Series E9000 - 1/2”, 3/4”, 1”, 1 1/4”, 1 1/2” I.D.se
These mobile base reels offer the greatest amount of stability
for high volume air, water, fuel and petroleum. Ideal for portable
service trucks, permanent service or plant work areas. A durable
baked-on powder coat finish produces a rugged corrosion
resistant product suitable for a wide variety of heavy duty
applications. Basic reels without hose will handle air, water
or oil; consult Reelcraft for other applications.
E9350 OLPBW
Hose Guide Roller Position
A suffix code (see diagram) must be added after the model # to
specify desired position. Reels are shipped in the BW position
unless specified otherwise. FF 95/9600 in BW only.
MODELS WITH HOSE HOSE CAPACITY MODELS WITHOUT HOSE
MODEL WEIGHT PRESSURE I.D. O.D. (M)NPTF
OUTLET
(F)NPTF
INLET LENGTH MODEL WEIGHT PRESSURE
lbs / kg psi / bar in / mm in / mm in in ft / m lbs / kg psi / bar
LOW PRESSURE AIR/WATER REELS* Maximum Temperature 150° F (65° C)
E9299 OLP 127 58 300 21 1 / 2 13 .844 22 1/2 1/2 100 31 E9200 OLP 115 52 500 35
E9350 OLP 140 64 250 18 3 / 4 19 1.188 31 3/4 3/4 50 15 E9300 OLP 115 52 500 35
FE9350 OLP § 140 64 50 3.5 3 / 4 19 1.188 31 3/4 3/4 50 15 FE9300 OLP 115 52 500 35
E9375 OLP 152 69 250 18 3 / 4 19 1.188 31 3/4 3/4 75 23 E9300 OLP 115 52 500 35
D9399 OLPBW 143 65 250 18 3 / 4 19 1.188 31 3/4 3/4 100 31 D9305 OLPBW 113 51 500 35
E9450 OLP 157 72 250 18 1 25 1.500 31 3/4 1 50 15 E9400 OLP 115 52 500 35
FE9450 OLP § 157 72 50 3.5 1 25 1.500 31 3/4 1 50 15 FE9400 OLP 115 52 500 35
NOT AVAILABLE WITH HOSE 1 1 / 4 32 1.750 45 1 1/4 1 1/2 50 15 FF9500 OLPBW 125 57 300 35
NOT AVAILABLE WITH HOSE 1 1 / 2 38 2.000 51 1 1/2 1 1/2 50 15 FF9600 OLPBW 125 57 300 35
MEDIUM PRESSURE OIL REELS** Maximum Temperature 210° F (99° C)
E9275 OMP 131 60 2000 138 1 / 2 13 .815 22 1/2 1/2 75 23 E9200 OMP 117 52 3000 207
E9350 OMP 142 65 1250 86 3 / 4 19 1.188 31 3/4 3/4 50 15 E9300 OMP 117 52 3000 207
HIGH PRESSURE GREASE REELS*** Maximum Temperature 210° F (99° C)
E9175 OHP 153 70 4000 276 3 / 8 10 .750 22 1/2 3/8 75 23 E9100 OHP 118 54 5000 345
§ Models equipped with fuel grade hose. UL330 and VLC approved hose. 250 PSI minimum burst (17 Bar) *Low pressure reels furnished standard with PVC hose. / **Medium pressure
reels are furnished standard with S.A.E. 100 R1T one wire braid hose. ***High pressure reels furnished standard with SAE 100R2T two wire braid hose suitable for grease applications only. For all
metric thread connections over 1/2" add the suffix number 70 to indicate BSPT threads - example E9300 OLP70. FF9500 and FF9600 models will have BSPP threads. Note: To specify our lighter
duty model, change prefix from E to D. Not available on FE9500 or FE9600. Modification - Reels without hose can be modified to handle gasoline and diesel fuel, to order place prefix "F"
before model number - example (FF9300 OLP). See Page 51 for inlet hose assemblies and adjustable bumper stops.
Made in USA
DIMENSIONS
E9000 FE9000 FF9000 D9000 D9399D9305
in / mm in / mm in / mm in / mm in / mm
J 3.75 95.3 7 178 7.75 197 7.75 197 7.75 197
A 12 305 12 305 17.8 451 12 305 13.3 337
X 7.75 197 7.75 197 13.5 343 7.75 197 7.75 197
Y 2.75 69.9 7.5 191 7.5 191 7.5 191 7.5 191
Four 7/16" (11.2mm) diameter mounting holes.
R
26.25
26.25
13.75
22.25
24.25
12.125
