Tie-Dex
®
II Tool - A40199
Precalibrated tool applies patented Tie-Dex
®
Bands. Weight: 1.2 Lbs (0.6 Kg).
Use the Calibration Key (A44699) to change calibration.
Micro Tie-Dex
®
II Tool - A30199
Precalibrated tool applies Tie-Dex
®
Micro Bands. Weight: 1.3 Lbs (0.6 Kg).
Use the Calibration Key (A44699) to change calibration.
Tie-Dex
®
II Kit - A49099
Weight: 4.3 Lbs (2.0 Kg).
Kit includes: 1-A40199, 1-A48599, 1-A44699, parts and cutters.
Tie-Dex
®
Micro Tool Kit - A59099
Weight: 4.6 Lbs (2.0 Kg).
Kit includes: 1-A30199, 1-A47599, 1-A44699, parts and cutters.
Tie-Dex
®
Gauge - A48599
Weight: 1.0 Lbs (0.5 Kg).
Tension gauge for A40199 tool. Used for verifying preset tension limits.
Micro Tie-Dex
®
Gauge - A47599
Weight: 1.0 Lbs (0.5 Kg).
Tension gauge for A30199 tool. Used for verifying preset tension limits.
Tie-Dex
®
Calibration Kit - A50099
Provides fast, easy, accurate calibration of all Tie-Dex
®
tools without a
dynamometer. Kit includes: 1-A50189, 1-A50599, 1-A50699, 1-A46687,
1 Mounting Bracket, 1 Hex Key and a Carrying Case. Weight: 4.3 Lbs (2.0 Kg).
Tie-Dex
®
Calibration Device - A50189
Weight: 1.2 Lbs (0.5 Kg).
Tie-Dex
®
Test Band - A50599
50 test bands. Weight: 0.3 Lbs (0.1 Kg).
Micro Tie-Dex
®
Test Band - A50699
50 test bands. Weight: 0.1 Lbs (0.06 Kg).
Tie-Dex
®
Micro Band
Maximum
Minimum
Diameter
Loop Tensile Package Package
Part No. Material*
Width
Length
Thickness Double Wrap Strength (Lbs) Quantity Weight
In mm In mm In mm In mm
Lbs Kg
A31188** 304 SS 0.120 3 8.1 207 0.015 0.38
0.9 23
200
100/box 0.4 0.2
A31189 304 SS 0.120 3 8.1 207 0.015 0.38
0.9 23
200
100/bag 0.4 0.2
A31089 304 SS 0.120 3 14.3 362 0.015 0.38
1.9 48
200
100/bag 0.7 0.4
Tie-Dex
®
Band
Maximum
Minimum
Inside Diameter Loop Tensile Package Package
Part No. Material*
Width
Length
Thickness Double Wrap Strength (Lbs) Quantity Weight
In mm In mm In mm In mm
Lbs Kg
A10088** 304 SS 0.240 6 14.3 362 0.020 0.51
1.8 46
700
100/box 2.1 1.0
A10089 304 SS 0.240 6 14.3 362 0.020 0.51
1.8 46
700
100/bag 2.1 1.0
A11089 304 SS 0.240 6 18.0 457 0.020 0.51
2.5 64
700
100/bag 2.5 1.1
**Individually coiled
A40199 Tie-Dex
®
II Tool
A49099 Tie-Dex
®
II Kit
A50099 Tie-Dex
®
Calibration Kit
A50189 Tie-Dex
®
Calibration Device
www.BAND-IT-IDEX.com
29
Tie-Dex
®
Bands
New Electronic
Version Coming
Soon!
*BAND-IT reserves the right to substitute material with equal or better
corrosion resistance and/or mechanical specifications.
