Page 14 - ABS150Mutipurpose(1)

SEO Version

Width (mm)
4
6
8
10 12 16 20 25
List List List List List List List List
Price Price Price Price Price Price Price Price
T5-410DL
82
$3.54 $5.70 $6.72 $7.74 $10.44 $12.54 $15.24 $19.68
T5-460DL
92
3.63 5.94 7.02 8.10 10.98 13.14 16.02 20.70
T5-590DL
118
4.05 6.68 7.83 9.12 12.34 14.84 18.16 23.56
T5-620DL
124
4.14 6.78 7.98 9.24 12.60 15.18 18.48 23.94
T5-750DL
150
4.44 7.38 8.82 10.20 13.92 16.80 20.46 26.64
T5-815DL
163
4.74 7.86 9.30 10.74 14.76 17.82 21.60 28.68
T5-860DL
172
4.84 7.98 9.60 11.12 15.18 18.36 22.36 29.16
T5-940DL
188
5.04 8.40 10.02 11.60 15.90 19.20 23.40 30.46
T5-1100DL
220
5.52 9.30 11.10 12.84 17.64 21.48 26.16 34.14
T-5 DL
Dual-sided
Belt
Length
& Pitch
Code
No.
of
Teeth
Urethane Timing Belts
- Dual Metric
Width (mm)
10
14 16
20 25 30 35 50
List
List List
List List List List List
Price Price Price Price Price Price Price Price
T10-260DL
26
$9.58 $13.07 $14.85 $17.89 $22.36 $26.71 $31.16 $43.68
T10-530DL
53
11.34 15.48 17.58 21.18 27.51 31.62 33.51 51.66
T10-630DL
63
12.48 17.22 19.56 23.58 30.72 35.46 37.56 58.14
T10-660DL
66
12.72 17.58 19.98 24.18 31.53 36.44 38.61 59.73
T10-720DL
7 2
13.62 18.84 21.42 26.04 33.93 39.24 41.58 64.59
T10-840DL
84
15.00 21.00 23.88 29.04 37.98 44.06 46.68 72.66
T10-920DL
92
16.16 22.62 25.86 32.33 40.41 48.49 56.57 80.81
T10-980DL
98
16.50 23.19 26.34 31.10 32.10 48.81 51.72 80.73
T10-1100DL
110
16.93 23.69 27.08 39.45 49.32 50.78 59.25 84.62
T10-1210DL
121
19.02 26.97 30.66 37.50 49.32 57.39 60.78 95.25
T10-1240DL
124
19.26 27.45 31.20 38.10 50.13 58.38 61.83 96.81
T10-1250DL
125
19.56 27.84 31.62 38.70 50.94 59.31 62.82 98.46
T10-1320DL
132
19.86 28.29 32.16 39.30 51.78 60.24 63.81 100.0
8
T10-1350DL
135
20.40 29.20 33.18 40.56 53.34 62.19 65.88 103.32
T10-1420DL
142
21.75 30.43 34.78 43.47 54.34 65.41 69.30 108.68
T10-1610DL
161
23.28 33.42 37.98 46.56 61.47 71.73 75.99 119.40
T10-1880DL
188
26.70 36.81 43.86 53.82 71.19 83.19 88.11 138.75
T-10 DL
Dual-sided
Belt
Length
& Pitch
Code
No.
of
Teeth
Dual Metric and Open End - Urethane Timing Belts
14
Width (mm)
6
8
10
12
16
20
25
32 50
T5
$1.75 $2.25 $2.90 $3.15 $4.40 $5.75 $6.75 $9.00 13.50
10 12
16
20
25
32
40
50
75
100
T10
$4.40 $4.40 $6.00 $6.30 $7.00 $9.00 $10.00 $11.00 $16.00 $22.00
25
32
50
75
100
T20
$9.00 $12.00 $19.00 $30.00 $42.00
6
10
16
20 25
32
50
AT5
$2.50 $3.50 $5.30 $6.70 $8.10 $10.80 $16.15
16
25
32
50
75
100
AT10
$7.00 $9.50 $12.00 $14.00 $20.00 $27.00
25
32
50
75
100
AT20
$11.50 $15.00 $24.00 $39.00 $54.00
Width (mm)
10
15
20 25
50
5mm
$4.50 $6.10 $10.50 $10.50 $17.00
10
15
20
25
30
50
85
8mm
$5.20 $8.25 $9.45 $10.35 $12.80 $16.00 $27.00
25
40
55
85
100
14mm
$14.95 $23.90 $32.70 $50.50 $62.00
Width-Inches
025
031
037
050
075
100
XL(1/5”)
$1.45
$1.75
$2.00
$2.70
$4.00
$5.40
037
050
075
100
150
200
L(3/8”)
$2.85
$3.10
$4.75
$5.70
$7.80
$9.15
050
075
100
150 200
300
400
H(1/2”)
$3.49
$5.40
$6.20
$8.50
$10.10 $15.00 $25.60
100
150
200
300
400
600
XH(7/8”)
$10.00 $15.00
$20.00 $32.00 $45.00 $69.00
List Prices Per Foot, Steel or Kevlar reinforced.
FDA construction add 10% to above prices.
Fabric covering toothside add 15% to above prices. • Fabric covering backside add 15% to above prices.
Standard roll lengths 100 meters (328 ft.). • Minimum order quantity 50 ft.
IMPORTANT:
For all bulk orders, we will ship the
full requirement in one continuous
piece if possible. If our stock does
not permit this, shorter lengths will
be used with no length being less
than 50 feet.
BELTS
•
Endless belts can be spliced to order.
•
Minimum Pitch length is 20”, except
T20 & 14mm where the minimum is
36” length.
•
Note: Splicing belts reduces horse-
power rating.
•
Consult Jason for pricing of spliced belts.
•
Always specify whether steel or Kevlar
reinforcement.
•
Consult Jason for pricing and availability
of special shapes and backings.
Urethane
, Steel or Kevlar reinforced belting
Resistant to moisture, oils, ozone, UV light and hydrolysis. Available in FDA Construction.
For additional information, please contact a Jason Sales Representative.
