62
DPL410
877.963.4966 • www.dixonvalve.com
Bayco Replacement Handle Assemblies
Pull Ring Safety Clips for Boss-Lock Couplings
Coupler
Size
Stainless Steel
Part #
Price/E
¾" - 1"
1¼" - 2½"
3" and 4"
6" and 8"
RHEZ175
RHEZ152
RHEZ34
RHEZ6
$20.60
23.60
37.10
60.00
•
investment cast stainless steel cam arm and lever
•
316 stainless steel spring
•
stainless steel pin, washer, plated carbon steel pull ring
Clips and Lanyards for Boss-Lock Couplings
Coupler
Size
Carbon Steel
Stainless Steel
Part #
Price/E
Part #
Price/E
¾" - 1"
1¼" - 2½"
3" and 4"
---
200PRSCCS
300PRSCCS
---
$1.55
1.60
100PRSCSS
200PRSCSS
300PRSCSS
$2.20
2.20
2.40
Coupler Size
Part #
Price/E
¾" - 1"
1¼" - 4"
ACL4
ACL2
$2.40
2.40
•
carbon steel clip
•
nylon lanyard
Stainless Steel Pull Rings
304 Stainless Steel
Part #
Price/E
R200SS
$1.30
Under no circumstances should the EZ Boss-Lock cam arms be used on any fitting not specifically produced for their use.
The aluminum, brass and iron are made from sand castings. To ensure proper functioning of the EZ Boss-Lock cam arm
assemblies, we sort the castings to ensure there is sufficient length and orientation on the lugs on the main casting to engage the lever.
We also buff or grind the rougher sand cast surface to ensure that the lever will move freely.
The EZ Boss-Lock cam arms cannot be
retrofitted onto existing aluminum, brass or plated iron Boss-Lock already in service.
Coupler
Size
Part #
Price/E
1¼" - 2½"
3" - 5"
6"
8"
CARP12BZ
CARP34BZ
CARP60BZ
CARP80BZ
$9.60
11.25
46.30
92.60
•
brass cam arm
•
carbon steel ring
•
stainless steel pin
for Bayco couplers only
•
carbon steel clip
•
no lanyard supplied with this clip
Coupler Size
Part #
Price/E
6"
ACL3
$4.90
