Hydraulic
These couplers and plugs have no internal valves, providing maximum flow with minimum pressure drop. Supplied with Buna-N
gasket seal. Interchanges with Parker-Hannifin SST/BST, Foster FST and Hansen ST couplings.
•
Do Not Disconnect with pressure in line
.
Female Couplers
Size
Thread
PSI
at 70°F
Material
Part #
Price/E Opt
Qty
1/4"
3/8"
1/2"
3/4"
1"
1-1/4"
1-1/2"
2"
1/4"
3/8"
1/2"
3/4"
1"
1/4" - 18
3/8" - 18
1/2" - 14
3/4" - 14
1" - 11½
1-1/4" - 11½
1-1/2" - 11½
2" - 11½
1/4" - 18
3/8" - 18
1/2" - 14
3/4" - 14
1" - 11½
4500
2700
2500
2000
1000
800
600
400
6700
5500
3000
3000
1700
brass
brass
brass
brass
brass
brass
brass
brass
303 stainless
303 stainless
303 stainless
303 stainless
303 stainless
STFC2
STFC3
STFC4
STFC6
STFC8
STFC10
STFC12
STFC16
STFC2SS
STFC3SS
STFC4SS
STFC6SS
STFC8SS
$7.30
9.00
13.00
25.00
36.00
99.12
135.85
187.15
47.30
67.00
78.00
135.65
185.00
12
12
12
12
1
1
1
1
5
5
5
5
5
Male Couplers
Size
Thread
PSI
at 70°F
Material
Part #
Price/E Opt
Qty
1/4"
3/8"
1/2"
3/4"
1"
1/4"
3/8"
1/2"
3/4"
1"
1/4" - 18
3/8" - 18
1/2" - 14
3/4" - 14
1" - 11½
1/4" - 18
3/8" - 18
1/2" - 14
3/4" - 14
1" - 11½
4500
2700
2500
2000
1000
6700
5500
3000
3000
1700
brass
brass
brass
brass
brass
303 stainless
303 stainless
303 stainless
303 stainless
303 stainless
STMC2
STMC3
STMC4
STMC6
STMC8
STMC2SS
STMC3SS
STMC4SS
STMC6SS
STMC8SS
$ 7.30
9.00
13.00
25.00
36.00
49.00
61.45
84.65
155.50
260.50
12
12
12
12
1
5
5
5
5
5
* Operating pressures for the standard hose barbs utilizing hose barb end connections may be dramatically reduced to that of
the hose rating and/or hose and end connection combination. Consult hose manufacturer's catalog for hose end connection
ratings. If in doubt, test under controlled conditions for suitability to application. Dixon cannot assume liability for misapplication
of products resulting in equipment down-time, lost production, property damage and/or personal injury including death.
Standard Hose Barbs
Size
Hose ID PSI *
at 70°F
Material
Part #
Price/E Opt
Qty
1/4"
3/8"
1/2"
3/4"
1"
1/4"
3/8"
1/2"
3/4"
1"
5200
2800
2200
1700
1700
brass
brass
brass
brass
brass
2ES2-B
3ES3-B
4ES4-B
6ES6-B
8ES8-B
$10.85
12.00
19.50
30.00
41.00
100
50
25
20
10
