110
DPL410
877.963.4966 • www.dixonvalve.com
E
Air
•
Dix-Lock is rated to
300 PSI
at ambient temperature (70°F)
Positive safety lock
With locking nut in place sleeve cannot be moved to open coupling.
Dix-Lock Gaskets
Body Size
Buna-N
Part #
Price/E
3/8"
1/2"
QBM1
QBM2
$1.31
1.31
Male Locking Head x Hose Shank
Body
Size
Hose Shank
Size
Material
Part #
Price/E
1/2"
1/2"
1/2"
1/2"
1/2"
3/4"
1/2"
3/4"
plated steel
plated steel
brass
brass
QM33
QM44
QB33
QB44
$30.84
30.04
41.34
41.34
Male Locking Head x Male NPT
Body
Size
NPT Thread
Size
Material
Part #
Price/E
1/2"
1/2"
1/2"
1/2"
1/2"
3/4"
1/2"
3/4"
plated steel
plated steel
brass
brass
QM66
QM88
QB66
QB88
$30.84
30.84
41.34
41.34
Male Head x Female NPT End
Body
Size
NPT Thread
Size
Material
Part # Price/E Opt
Qty
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
3/8"
1/2"
3/4"
1"
3/8"
1/2"
3/4"
1"
3/4"
plated steel
plated steel
plated steel
plated steel
brass
brass
brass
brass
stainless steel
QM81
QM82
QM83
QM85
QB81
QB82
QB83
QB85
QSS83
$22.51
22.51
22.51
24.91
35.45
35.45
35.45
37.01
76.31
25
25
25
25
--
--
--
25
--
Female Head x Female NPT End
Body
Size
NPT Thread
Size
Material
Part # Price/E Opt
Qty
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
3/8"
1/2"
3/4"
1"
3/8"
1/2"
3/4"
1"
3/4"
plated steel
plated steel
plated steel
plated steel
brass
brass
brass
brass
stainless steel
QM101
QM102
QM103
QM105
QB101
QB102
QB103
QB105
QSS103
$18.24
18.24
18.24
20.10
27.28
27.28
27.28
29.95
55.89
25
25
25
25
-
-
-
25
-
