8
DPL410
877.963.4966 • www.dixonvalve.com
Pressure Recommendations
Couplings
The images shown on these two pages are provided to assist in coupling and clamp or ferrule identification for the pressure
recommendation chart on pages 10 - 13.
Dixon Cam & Groove
Machined Short Shank
Holedall Internal Expansion
Boss Couplings
Cast Short Shank
Flow Chief / Sanitary
Air King Universal
Push-On
Holedall Internal Expansion Petroleum
King Machined Medium Shank
Reusable Brass
Flat Seal
King Machined Long Shank
Holedall Swage / Crimp
