Municipal
Rubber Covered Fire Hose
Hi-Combat Lite
High Performance Lightweight
Large Diameter Supply Hose
Angus Hi-Combat Lite is a range of lightweight
performance upgraded through-the-weave high
pressure supply lines. This family of supply hose,
available in 3", 4" and 5", operates at above normal
pressure rates usually associated with standard supply
lines. Hi-Combat Lite provides extra safe operating
pressure without compromising for a heavy weight hose
design. The standard color for Hi-Combat Lite is yellow.
Hi-Vol
Large Diameter Supply Hose
Angus Hi-Vol is a tough large diameter hose with the
ability to deliver more water at a lower cost. But it
doesn’t stop there. It is lightweight, compact and durable
with a high resistance to oils, chemicals, ozone and heat.
Its tough, high tensile cover and lining, permanently
interlocked with the synthetic reinforcement, provide
greater abrasion resistance while being snag-proof, kink
resistant, and immune to mildew or rot. U.L. labeling is
available on 4” (100 mm) and 5” (125 mm) only. The
standard colors for Hi-Vol are yellow or red (6” not
available in red).
Angus Hi-Combat Lite
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
3 75 300 2100 600 4200 900 6300 3-13/32 87 36 16.2 18-3/8 467
4 100 250 1750 500 3500 750 5250 4-5/16 110 46 20.7 17-1/2 445
5 125 225 1575 450 3150 675 4725 5-3/8 137 56 25.2 18-7/8 479
Angus Hi-Vol
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 100' (30m) 100' (30m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
3 75 300 2100 600 4200 900 6300 3-13/32 87 70 31.5 25 635
4 100 225 1575 450 3150 675 4725 4-5/16 110 90 40.5 24 610
5 125 200 1400 400 2800 600 4200 5-3/8 137 109 49.1 27 686
6 150 150 1050 300 2100 500 3500 6-15/32 164 135 60.8 32 813
* Weight is uncoupled
