BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
56 KRHCA0109
Specialty Hoses
APPLICATION
To convey cooling water to furnace doors in steel mills, glass
plants, foundries, or where the hose is subjected to high
temperatures and splashes of white-hot molten metals or glass.
COVER
Heat resistant tan EPDM, non-conductive resin-coated
dust-free fberglass cover.
REINFORCEMENT
High tensile textile cords.
TUBE
White EPDM rubber.
TEMPERATURE RANGE
Tube: -40°F (-40°C) to 248°F (+120°C)
Cover: -40°F (-40°C) to 1000°F (up to +540°C)
STANDARD LENGTH
100 feet
T957LL - 150 PSI Furnace Door Coolant Hose
T957LL050 1/2 13 0.98 25 30 150
T957LL175 3/4 19 1.30 33 47 150
T957LL100 1 25 1.54 39 58 150
T957LL125 1 1/4 32 1.89 48 84 150
T957LL150 1 1/2 38 2.13 54 98 150
T957LL200 2 51 2.64 67 126 150
T957LL250 2 1/2 63 3.19 81 154 150
T957LL300 3 76 3.78 96 213 150
Nominal Specifcations
SERIES NO. NOMINAL ID NOMINAL OD APPROX. WT. MAX. REC.
(in.) (mm) (in.) (mm) lbs./100 ft. WP (PSI)
KRHCA 09
