BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
48
KRHCA0109
FDA Material Handling
T760LB - 75 PSI Dry Bulk Food Discharge
Hose - FDA Grade
APPLICATION
Discharge or delivery of dry bulk food products.
COVER
Grey SBR/EPDM – abrasion and ozone resistant.
REINFORCEMENT
Spiralled high tensile textile cords and static wire.
TUBE
3/16" white NR – abrasion resistant.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet.
BRANDING
ALFAGOMMA – ITALY T760 5 BAR (75 PSI) – BULK FOOD &
MATERIAL DELIVERY (in white letters)
COUPLING SUGGESTIONS
Quick-Acting coupling attached with bands.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
H
Please note: Proper grounding of static wire will prolong tube life.
T760LB400
4
102
4.65
118
212
75
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MIN. REC.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
KRHCA 09
