BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
40
KRHCA0109
Petroleum
APPLICATION
For suction and discharge applications in truck and tank car
transfer of gasoline, oil and other petroleum-based products
with up to 50% aromatic content.
COVER
Black CR – abrasion, ozone and hydrocarbon resistant.
REINFORCEMENT
High tensile textile cords and steel helix wires.
TUBE
Black conductive NBR.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet: 3/4" through 6"
20 feet: 6", 8"
WORKING PRESSURE
Constant Pressure 150 PSI
BRANDING
ALFAGOMMA – ITALY T605 – 10 BAR (150 PSI)
PETROLEUM – S & D (in red letters)
T605AA - 150 PSI Black Petroleum Suction Hose
COUPLING SUGGESTIONS
Quick-Acting, combination nipples attached with bands or internally expanded brass couplings with gasket seal attached with
ferrules.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T605AA075
3/4
19
1.14
29
40
3
T605AA100
1
25
1.38
35
50
4
T605AA125
1 1/4
32
1.65
42
60
5
T605AA150
1 1/2
38
1.89
48
69
6
T605AA200
2
51
2.40
61
89
8
T605AA250
2 1/2
63
2.95
75
140
10
T605AA300
3
76
3.46
88
167
12
T605AA400
4
102
4.57
116
228
16
T605AA600
6
152
6.69
170
481
24
T605AA800
8
203
8.86
225
782
32
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
RADIUS (in.)
H
T605 is not recommended for use on a reel.
